NEXANS JOINTS | TERMINATIONS | CONNECTORS
Thorne & Derrick International are the UK largest stockist and supplier of Nexans Power Cable Accessories & Euromold Connectors - this newsletter provides product overviews, training videos, installer tips and technical articles.
Nexans manufacture MV Cold Fit, Heat Shrink, Slip-On and EPDM Rubber Connectors, Joints & Terminations up to 66kV.
T&D distribute LV-HV Cable Installation, Jointing & Electrical Equipment - we service UK and global businesses involved in cable installations, jointing, substation and electrical construction at LV, 11kV, 33kV and EHV.
Bushing Interfaces & Euromold Connectors
This Technical Article enables the correct selection of Nexans Euromold connectors depending on a) cable specification and b) equipment bushing type (A, B, C, D, E or F) - an informative overview of the 6 Bushing Interfaces common to MV electrical equipment.
How To Select & Specify MV HV Switchgear & Transformer Connectors
Nexans JTS | MV Cable Joints
Reliability & Safety at Reduced Cost
A modern generation of MV Heat Shrink Joint has been developed by Nexans for Medium Voltage Connections - the primary application is for the jointing of 11kV/33kV single and 3 core cables (BS6622 BS7870).
Nexans JTS cable joints provide the most cost-competitive option to contractors - watch video.
Nexans Mono | MV Cable Terminations
Electrical Reliability | Stress Control | Moisture Sealing | Track Resistant
Nexans MONO heat-shrinkable medium voltage terminations feature integrated stress control for reduced shrinking and reduced error scope by the jointer up to 42kV.
MONO 11/33/42kV cable terminations provide stable performance under severe environmental conditions with exceptional tracking and erosion resistance, mechanical strength, weatherability and dielectric properties
MONO indoor and outdoor cable terminations are designed for a maximum system voltage of 42kV
Euromold Screened Separable Connectors
The Difference Is Material - EPDM
EPDM rubber performance levels excel in electrical strength and resistance to environmental conditions compared to competitor connector materials, such as silicone.
Compliant to CENELEC HD 629.1 S2 and approved by all UK DNO's - no service life issues or product breakdowns for converter-based applications in onshore/offshore windfarm and solar power projects.
Further Reading
Nexans Euromold range of Connectors & Bushings have now received Full Acceptance by Network Rail with Official PADS Approval.
Specifically this includes Nexans Tee Connector model QM909TB Interface F and associated equipment Bushing QM909AR. Also the AFN36-6 single core MV cable terminations.
Thorne & Derrick are currently supplying this range of transformer terminations to several UK rail projects – we are Approved Vendors to Network Rail, Framework Delivery Partners and several HS2 Joint Ventures working on rail transport projects.
Thorne & Derrick, are pleased to confirm the market leading Nexans Euromold brand of Screened Separable Connectors now hold the Approval for supply within SSE’s networks business.
SPEN Scottish Power Approved Kits | 33kV Transformer Connectors | Nexans Euromold
Create Revenue Sooner with 30% Reduced Installation Costs
Nexans Offshore Junction Cabinets (OJC) improve revenue streams for offshore wind power developments – the cabinets are used as a disconnecting point for internal tower cable to external subsea array cables.
This can be used as a demarcation point between tower, transition piece and array cable related parties – Nexans OJC junction cable chambers enable earlier completion dates.
Nexans Webisodes
Watch & Learn
Nexans have created a 4 part series of Webisodes answering FAQ's about their Euromold Connectors.
Understand IP ratings, learn how to bevel XLPE insulation, install connector caps and clamp separable connectors onto mating bushings.
Thorne & Derrick have created a 4 Part Blog Series to compliment the videos.
MV Cable Jointers Tool Kit
Nexans have combined complementary tools into one kit – Nexans Expert Tool Kit – allowing Jointers to hold all Preparation Tools in a single portable kit.
Contents includes leading brand Tools from Alroc and Ripley for the removal of cable sheath/jacket, semi-con screen and insulation from MV cables up to 33kV.
Invest in the correct Jointing tools, get trained in their use and use them.
Jointer Competency Training Courses
11kV, 33kV & 66kV
Images Courtesy : Jon Rhodes (Technical Customer Manager – PCABU – UK & Ireland at Nexans Power Accessories).
We work with Nexans, who deliver MVHV Competency Certified Training Courses to support the training requirements for Cable Jointers upskilling, with tailored courses.
High quality training is key to achieving the advanced skill-set when working on cable systems and can unlock career progression opportunities up to 66kV.
Be competent, not just familiar.
Pictured: US02 MAX - The Jointing Tool is shown acing the HV Prep of 66kV/72kV 1200sqmm single cable XLPE insulation with bonded semicon screen – minimal polishing and chamfering required with a clean and precise transition up to 80mm.
