JOINTING CABLES | LV to HV
Thorne & Derrick supply from large UK stocks the complete range of Cable Joints from 3M Electrical in both Scotchcast and ColdShrink technology - suitable for power, instrumentation and control cables with XLPE, EPR, PVC or PILC insulation, 600/1000v up to 66kV.
Power & General Cables
Fire Resistant (FP) | Sea Water Resistant (Subsea)
Low Smoke Zero Halogen (LSZH & LSF)
Hydro Carbon Resistant (ATEX | Hazardous Areas)
Flexible | Trailing & Reeling Cables | Inter Array Cables
INNOVATIVE SCOTCHCAST DESIGN
The new design of resin cable joints from 3M Electrical features safer mould bodies along with the Scotchcast™ resin delivery system.
3M Resin Cable Joints offer reliability and fast installation. With the use of constant force springs, the need for difficult manipulation of armour wires is eliminated - resulting in a more efficient armour continuity process.
Cable joints specially modified for onshore and offshore wind, solar, rail, oil/gas, data centre, battery storage and utility cables are available - suitable for direct burial (underground) or onto cable containment.
Technical & Specification Support available from Thorne & Derrick.
Resins are used as part of the process to create electrical cable joints for LV MV HV fault repair and installations.
2 part cable resin is quick to mix and pour using a Closed Pour delivery system – specialist cable jointing resins include hydrocarbon resistant, low smoke zero halogen, fire resistant and flame retardant.
The Scotchcast resin bag is designed to remove any chance of skin contact and reduce vapour inhalation from the resin itself, giving the user superb control over the resin mixing and pouring process and avoiding unnecessary spills and wastage.
3M LVI-3 Scotchcast resin cable joint kits are designed to be used for multi-pair or multi-core Power, Control & Instrumentation cables in explosive atmospheres (Zone 1 & Zone 2).
The cable joints include specially formulated 3M Scotchcast 1402FR resin – this resin is hydrocarbon resistant, flame retardant, halogen free and chemical resistant for use in hazardous area locations.
Joint | Terminate | Seal | Insulate | Repair | Abandon | Cap
COLD SHRINK
LV MV HV
Simple and safe to install without requirement for “hot-working” to provide effective and reliable performance for LV MV HV cable systems – excellent mechanical protection and electrical insulation with range-taking tubes or assembled kits to enable the maintenance and repair of cables demonstrating thermal stability, water-resistant and high-levels of resistance to acids, alkalis and ozone.
Cold Shrink Benefits | reduces the scope for Jointer errors (easier), less tooling is required (efficiency), no naked flames required (safer) and guaranteed industry leading performance according to recorded failure rates (reliable).
600V TO 66KV JOINTS & TERMINATIONS
THORNE & DERRICK stock Joints & Terminations from 3M Electrical for the connection of Medium & High Voltage Power Cables up to 66/72.5kV from stock - this includes 11kV/33kV Industrial & DNO, 25kV Network Rail (PADS) and 66kV Terminations and Joints with National Grid Type Registration and global Approvals for Inter-Array Cable Test & Termination applications.
LV HV CABLE INNOVATION TOOLS
THORNE & DERRICK are Specialist Distributors of Ex Stock Innovation Tooling to facilitate safe and reliable cut/crimp, spiking, preparation, termination and installation of cables.
CABLE ACCESSORY STOCKISTS UP TO 66KV
CABLE TERMINATION, JOINTING, PULL-IN & ELECTRICAL EQPT UP TO 66KV
Thorne & Derrick are specialist distributors of LV, MV & HV Cable Installation, Jointing, Earthing, Substation & Electrical Eqpt – servicing UK and global businesses involved in cable installations, jointing, substation, overhead line and electrical construction at LV, 11kV, 33kV and EHV.
We supply the Power Transmission & Distribution industry in the onshore and offshore wind, solar, rail, oil/gas, data centre, battery storage and utility sectors.
