Südkabel Training | Cable Terminations 72.5kV – 132kV | Jointer Training Services

Published 14 Oct 2020

Sudkabel

Jointer Training MV HV EHV

Sudkabel Terminations

Jointer Training

72.5kV – 132kV Medium & High Voltage Cables

Südkabel are global leaders in manufacturing Extra High Voltage EHV cable joints and cable terminations for XLPE insulated cables also offering an outdoor termination portfolio including the dry type solutions.

The outdoor cable terminations are available between 72.5kV-132kV offering both the self supporting and rigid dry type solution – a Jointer Training Service is also available by contacting Thorne & Derrrick for further information.

➡ The following tables provides an overview of the range of Südkabel Cable Terminations available for the connection, support and sealing of high voltage cables.

EHFVCS EHFS EHFSI EHFST
EHFVC
compound filled
composite insulator
EHFV
compound filled
porcelain insulator
EHFVCS
pluggable & dry-type
gas-filled
composite insulator
EHFS
flexible
dry-type & gas-free
EHFSI
flexible
self-supported
dry-type & gas-free
EHFST
self-supported
dry-type & gas-free
Voltage Um up to 550 kV up to 550 kV up to 550 kV up to 145 kV
limited
up to 245 kV
up to 145 kV
limited
up to 245 kV
up to 170 kV
BIL Û up to 1550 kV up to 1550 kV up to 1550 kV up to 650 kV up to 650 kV up to 750 kV
Cross Section up to 3200 sqmm  up to 3200 sqmm  up to 3200 sqmm up to 1200 sqmm
lager on request
up to 1200 sqmm
lager on request
up to 1200 sqmm
lager on request
Creepage
Distance
≥ d / III – heavy
IEC 60815
≥ d / III – heavy
IEC 60815
≥ d / III – heavy
IEC 60815
≥ d / III – heavy
IEC 60815
≥ d / III – heavy
IEC 60815
≥ d / III – heavy
IEC 60815
Connector compression or
screw connector
compression or
screw connector
compression or
screw connector
compression or
screw connector
compression or
screw connector
compression or
screw connector
Suitable for water
protection areas
limited limited yes yes yes yes
Installation
position
normally ≤ 30° normally ≤ 30° arbitrary normally ≤ 45°
resp. upside down ≤ 45°
arbitrary normally ≤ 45°
Add-ons OF decoupling
rotatable base plate
arcing horn
PD sensor
OF decoupling
rotatable base plate
arcing horn
PD sensor
OF decoupling
rotatable base plate
arcing horn
PD sensor
OF decoupling OF decoupling OF decoupling
rotatable base plate
arcing horn
PD sensor

About Südkabel

At Südkabel, we are proud of our heritage and everything that has been developed and achieved in Mannheim for more than 100 years. After all, we don’t just produce high quality cables and accessories, but also accomplish pioneering work – particularly in the field of XLPE technology.

This progress is supported by people with a wide range of qualifications and experience. They all distinguish Südkabel’s image. They all drive the company forward and always work in the interest of their customers.


THORNE & DERRICK

Thorne & Derrick are national distributors of LV, MV & HV Cable Installation, Jointing, Substation & Electrical Equipment – servicing businesses involved in cabling, jointing, substation, earthing, overhead line and electrical construction at LV, 11kV, 33kV, 66kV and EHV. Supplying a complete range of power cable accessories to support the installation and maintenance of low/medium and high voltage cable systems:

  • Slip-on Cable Terminations
  • Cold-shrink Cable Terminations
  • Heat-shrink Cable Terminations
  • Cable Joints – Heat & Cold-shrink
  • Separable Connectors (Euromold)
  • Surge Arresters & Switchgear/Transformer Bushings

Key Product Categories: Duct Seals | Cable Cleats | Cable Glands | Electrical Safety | Arc Flash Protection | Cable Jointing Tools | Cable Pulling | Earthing | Feeder Pillars | Cable Joints LV | Joints & Terminations MV
