Cable Lugs & Connectors

Cable Lugs Splices Connectors Pfisterer Sicame

Cable Lugs, Connectors & Crimps

Cable Lugs, Connectors & Crimps

Cable Lugs & cONNECTORS

Connecting, Jointing & Terminating LV MV HV Cables

The complete range of electrical connectors and cable lugs for jointing and terminating cables and connecting conductors into low, medium and high voltage switchgear, control panels and transformers using compression (crimping) or mechanical shearbolt (“snap-off”) type connectors.

Connectors are available to lug, crimp and splice cables for LV, MV and HV applications with copper or aluminium conductors ranging from 1.5sqmm up to 1200sqmm.

Compatible with 11kV and 33kV cold shrink, heat shrink, push-on and slip-on type cable joints and cable terminations – crimp, shearbolt and brass tunnel type connectors suit for resin cable joints.

  • Cable Lugs & Electrical Connectors
  • Low Voltage 600/1000 Volts (3.3kV)
  • Medium Voltage 6.6kV 11kV 33kV
  • High Voltage 66kV 72kV
Cable Lugs & Electrical Connectors

Cable Lugs & Electrical Connectors | Connectors manufactured by Cembre are produced using electrolytic copper with a minimum purity of 99.95% and aluminium with a purity greater than 99.5%. Copper connectors undergo an annealing process in order to optimise the structural characteristics of the metal.

Cable Lugs & Connectors LV MV HV

Complete range of copper, aluminium and bi-metallic cable crimp lugs, connectors and splices to compress all types of LV-HV cable conductors up to 33kV.

Cembre lugs and connectors are manufactured from high purity and conductivity copper with range of installation tools for matched crimping system including hydraulic crimping tools and battery operated crimpers.

Also – 11kV Medium Voltage Cable Lugs (MV), 33kV High Voltage Cable Lugs (HV), Copper C Sleeve Connectors, Low Smoke Zero Halogen Connectors, Insulated Cable Terminals, Colour Coded Copper Cable Lugs, Transformer Lugs.

Overview of Cembre Cable Lugs for Crimping & Connecting Copper & Aluminium

Cembre Lugs | S Range

Cembre Lugs | S range cable terminals are manufactured from electrolytic copper strip and tin plated. The seam is brazed to provide uniform mechanical strength. The terminal barrel is rifled to enhance electrical contact to improve mechanical strength. The connectors are manufactured by Cembre from electrolitic Copper Cu-ETP CWOO4A according to UNI EN 13599 and are tin plated with a minimum thickness of 3µm.

Cembre Lugs | Ring Tongue Terminals with Contained Palms

Cembre Lugs | this range of cable lugs features contained palm width specifically designed for application with Low Voltage circuit breakers with reduced space terminal blocks. In fact the contained palm width of the Cembre lug allows an immediate and easier installation – cable lugs are manufactured from electrolytic copper tube with a designed section of the barrel and the choice of principal dimensions for optimising the best combination of mechanical strength and electrical conductivity. Cembre lugs are manufactured from electrolytic copper tube Cu-OF CW008A conform to UNI EN 13600.

Cembre Lugs | A-L Series Lugs Angled 90°

Cembre Lugs | the A-L series lugs angled 90° are manufactured from electrolytic copper tube. The dimensions of the tube are designed to obtain the most efficient electrical conductivity and mechanical strength to resist vibration and pull out. Cembre cable lugs are annealed to guarantee optimum ductility which is an absolute necessity for connectors which will have to withstand the severe deformation arising when compressed and any bending of the palm during installation.

Cembre Lugs | A-2M Series Cable Lugs

Cembre Lugs | A-2M series lugs are manufactured by Cembre from electrolytic copper tube. The dimensions of the cable lug tube are designed to obtain the most efficient electrical conductivity and mechanical strength to resist vibration and pull out. UL listed for US and Canada per UL486A up to 35kV.

Cembre Lugs | Transformer Cable Lugs | 4 Hole

Cembre Lugs | A-4ESI series cable lugs lugs are made from high purity electrolytic copper tube, annealed and tin plated with a four hole stud fixing in accordance with E.A. specifications ensures compatibility with most transformer fixing arrangements from 600V to 11kV.

➡ See complete range of LV Cable Lugs.

Cable Lugs & Connectors LV MV HV

Sicame Mechanical Shearbolt

Sicame cable jointing connectors for LV-HV underground cable networks – mechanical connectors utilising shearbolt connection technology manufactured from copper, brass or aluminium.

Specialist LV Cable Jointing Connectors – Service Straight, Service Branch, Mains Straight, Service & Branch, Waveform Connectors, Termination Lugs, Termination Connectors for utility cables 600/1000V. MV-HV straight, branch, service connectors and termination lugs available for 11kV-33kV.

Cable Lugs 11kV

Utility Joints & Connectors To UK DNO Standards Including Mains & Service Jointing

Mechanical Cable Lugs & Connectors MV HV

Pfisterer Sicon

Pfisterer Sicon screw type bolted connectors are installed directly onto cable conductor ends (lugs) or to connect sections of jointed cable at medium/high voltages – typically used to connect cables at 11kV-33kV with voltage rating suitable also for HV up to 66kV/72kV. Network Rail PADS approved connectors.

Pfisterer Sicon offer a range of mechanical shearbolt cable connectors with stepless shear-off bolts providing the right connector for any applications. For years now, bolted clamps, connectors and cable lugs have been gaining ground as bolted connectors offer technical and practical advantages that compression technology cannot match.

Sicon bolted connectors are installed directly onto the ends of the conductor with a standard allen key aiding simple and smooth installation. The innovative design of the stepless shear bolt allows installation regardless of the conductor type. Thanks to the special design of the bolt, optimal contact force is always achieved.

All Sicon cable lugs and connectors can be easily installed, even under tight spots. The bolt shears off smoothly when it is tightened. The remains stay in the tool and can be safely disposed of. The bolt always shears off at the top edge of the connector body. This way, there are no sharp protrusions. All edges of the connector body are rounded.

Every Sicon connector covers a wide cross-section range. This way, you always have the right connectors with on site. And even if during repair work it is unclear type of conductors must be connected and in which condition are they in, Sicon is the right choice. Sicon connectors are electrically/mechanically type-tested in accordance with IEC 61238-1 class.

Sicon shear bolt connectors can be manufactured to meet the customers unique specification. Please contact T&D for further information.

Pfisterer Sicon Cable Lugs Connectors 11kV 33kV

Pfisterer Sicon Cable Lugs & Connectors – stepless shearbolts for jointing and terminating 11kV, 33kV and 66kV power cables

➡ View complete range of Cable Lugs & Connectors for LV, MV & HV applications.
