The Distribution Network Operator (DNO) Transition to Distribution System Operator (DSO)

Published 15 Nov 2019

Distribution Network Operator

Dr Vincent Thornley, Technology Director, Fundamentals Ltd

  • Republished with the kind permission of Fundamentals Ltd
  • Uploaded by Chris Dodds (Sales | Marketing Manager at Thorne & Derrick)

Fundamentals Ltd recently held an industry event “Electricity Networks: Health, Performance and Transformation of the Grid”, and the transition to DSO featured in a number of presentations across the day, not just limited to the Transformation session.

A common theme for many of the speakers was clarity around a common objective, whether this related to DSO transition, solving customers’ problems, delivering services or building the 1000mph Bloodhound car.

 Wrestling with Transformation

In essence, the GB electricity industry is undergoing an introspective period as it wrestles with its latest transformation project: Distribution System Operator (DSO).

Each of the current participants have their own view of what it is to be a DSO, which will naturally support their own business strengths. In the end it is Ofgem who may decide the scope through the licences it issues for the next regulatory period, ED2.

Customers of the electricity system and wider stakeholders are demanding greater flexibility, greater security, the ability to use more sustainable sources of electricity and to put it to wider use (e.g. transport), and all without huge increases in the cost of energy.

We need to keep in mind that a move to DSO should only be to support stakeholder needs such as these, rather than for its own sake.

Any attempt to define DSO results in extended discussion about what it is and everyone has a slightly different view.

The process should be to define the required roles (or functions) of the electricity system at distribution level, and for this a good starting point is a model already in use at transmission and market level: the ENTSO-E/EFET/eBIX Harmonised Electricity Market (HEM) Role Model.

A role-based model defines the functions required and the interaction between roles and domains of operation. Different actors can then take on combinations of these roles.

DNO

DNO vs. DSO | Image PPL

 Working in Harmony?

The HEM role model is concerned primarily with the interactions between transmission systems, but the model and its definitions can be extended to the distribution layer.

The ENA Open Networks project seeks to define the functions of a DSO. However, rather than defining the entity of a DSO, taking a role-based approach including licensing could yield a number of key benefits:

  1. A more granular approach to licensing network and system services by the regulator. Ofgem could choose to licence different roles to different actors, and these may not be uniform throughout GB. It opens up the possibility of different operating models in rural settings to urban centres, which could include multi-utility system operation, or have a role provided by a city municipality.
  2. Alternative methods of delivery of some of the functions by different operators. An example of this is some of the ancillary service functions being delivered byElectricity North West’s CLASS project, within which Fundamentals is playing a significant role.
  3. Flexibility to adjust the licensing model as techniques develop. Indeed, within the bounds of operator suitability assessment, trading of licences could be allowed, reaching a more favourable operating point for the system. This will also enable new market entrants in the system.
HV Electrical Equipment

CLASS | Electricity North West, a UK DNO, has started rolling out a revolutionary way of reducing demand for electricity across the North West, without anyone noticing a difference to their power supply.

Conclusion

Overall, the industry now requires a laser-like focus on the reason for the transformation: solving the energy trilemma.

Experts In hv Grid Control

Transformers

Upgrading MV HV Transformers

With more than 20 years’ experience in grid control, Fundamentals are the only company to bring you an end-to-end engineering service that covers everything from consultancy, design and installation through to maintenance and ongoing support.

Fundamentals core expertise relates to voltage control for electrical power networks.

This comes from a deep understanding and practical experience of on-load tap changers, control schemes and the electrical network itself.

Building on this expertise, Fundamentals have developed a comprehensive range of services to fully support you on site for grid control.

  • Total Tapchanger Solutions
  • Protection and Control Schemes
  • Transformer Upgrade Solutions
  • HV Substation Services
  • For more go to Company Voice

Pictured: Total Tapchanger Solutions – an innovative service from Fundamentals, with subsidiary Ferranti Tapchangers, provides an unrivalled one-stop-shop solution for all types of tapchangers and related control systems.
