Panduit Cable Cleats For Short Circuit Protection

Panduit Cable Cleats

Short Circuit Protection of LV MV HV Cables

Panduit working with Thorne & Derrick, their UK Distributor, have an extensive line of cable cleat solutions that ensures cables remain contained in the event of a short circuit fault, minimising disruption and damage to personnel and property.

Panduit’s Cable Cleats are uniquely engineered for ease of installation in a range of applications and harsh environments. With a variety of cable cleats, Panduit has the right product to fit your needs while providing on the job productivity, reliability and safety.

Cable Cleats

Blog | Cable Cleats v Cable Strapping Bands | A White Paper by Panduit

Thorne & Derrick | Distributors

Network Infrastructure & Industrial Electrical Wiring

Should you require customer service, specification support or a competitive quotation please do not hesitate to contact us – extensive range of Cable Accessories, Protection & Management products available for LV MV HV Electrical Infrastructure projects in commercial, industrial and hazardous area sectors.

With a variety of cable cleats Panduit has the right products and tools to meet your needs:

Mounting brackets for LV MV HV cables
Stainless steel locking ties
Stainless steel aluminium and plastic cable clamps
Stainless steel straps and cable ties

What is a Short Circuit?

Short Circuit is caused by:

Low Resistance – connection between conductors that results in excessive current flow in the power source
Internal Effects – breakdown of equipment or conductors from deterioration
External Effects – insulation failure due to lightning surges, overloading equipment

Typical circuit breakers trip or interrupt a fault.

Breakers trip between 0.06 and 0.1 seconds
Max electromechanical stress occurs at or before 0.005 seconds
Resistance to electromechanical forces within 0.005 seconds

Panduit Cable Cleats

Provide a safe work environment
Prevent downtime and lost revenue
Reduce serious workplace injuries
Reduce collateral damage to equipment

Panduit test their cable cleats to the strictest and most globally recognised standards IEC 619194:2015. Panduit’s R&D team has created a simulation cable cleat programme which simulates the forces present in a short circuit preparing the cable cleats for testing against IEC 619194:2015 and validating compliance with the standard.

Choosing the right cable cleat can be a time consuming process.

Traditional Cable Cleat Selection Cleat Process

Customer sends parameters to the cable cleat manufacturer
The manufacturer’s engineering team performs calculations
Customer waits to hear from manufacturer
Manufacturer provides cable cleat recommendation
Customer selects cable cleat based recommendations

Panduit have released a new quick and easy cable cleat product selector app that streamlines the selection process. The only data required to be inputted is the cable cleat diameter and peak short circuit current requirement and the app will calculate and recommend Panduit cable cleats and provide IEC 619194:2015 cable spacing.

The cable cleat solutions are designed for a wide range of vertical markets including:

Petrochemical
Oil & Gas
Shipbuilding
Rail & Tunnel

Verisafe is an electrical safety product manufactured by Panduit that automatically isolates electrical control panels and distribution boards

Thorne & Derrick are Specialist Distributors to the UK and international industries to provide safe and reliable LV HV Electrical Cable & Power Distribution Systems up to 66kV – we are highly customer responsive and absolutely committed to providing a world-class service.

Contact our UK Power Team for competitive quotations, fast delivery from stock and technical support or training on all LV-HV products.
