Furse
Copper is used for most installations due to its high conductivity, anti-corrosive properties, and its flexibility for use in-air, in-earth and in-concrete forming part of the Furse range of conductors.
Furse hard drawn copper bar is available in a range of sizes to meet differing current ratings see the table below
Furse Product Details
-
Tinned copper variants available to special order
-
Hard drawn copper bar supplied unbranded
Earthing Standards
- BS EN 13601
| Furse Hard Drawn Copper Bar | Overall nominal size (mm) | Approximate length (m) |
Weight per metre (kg) |
| BA205 | 25 x 3 | 3 | 0.67 |
| BA210 | 25 x 6 | 4 | 1.33 |
| BA225 | 38 x 6 | 4 | 2.03 |
| BA230 | 50 x 6 | 3 | 2.67 |
| BA235 | 50 x 10 | 4 | 4.45 |
| BA240 | 75 x 6 | 4 | 4.00 |
| BA250-FU | 100 x 6 | 4 | 5.38 |
