ELLIS Solus Single Cable Clamps For Non Metallic Market

Published 06 Jul 2021

Solus Single Cable Clamps

Non Metallic Single Cable Clamps

Ellis Solus Single Cable Clamps for Cleating Cables

Ellis Patents have boosted the strength of their cable clamps and cleats range with the launch of Solus single cable clamps. This range of non-metallic single cable clamps are suitable for cables from Ø25 to Ø75mm. Designed, developed and manufactured in-house by Ellis, Solus cable clamps are made from a high strength, glass-filled nylon and joins Trident – a trefoil clamp – as part of their expanding non-metallic product range.

Single Cable Clamps

Features

Short circuit & mechanically tested in accordance with IEC61914
Cleats manufactured from high grade heat stabilised polymer
Suitable for indoor, outdoor and harsh environments
Long design life
Easily stacked cable clamps for multiple cables and circuits
Large cable range (fewer clamps sized to stock)

ELLIS Solus Single Cable Clamps For Non Metallic Market

Danny Macfarlane, Managing Director of Ellis Patents, said: “Non-metallic cable cleats have been very popular in mainland Europe for many years, and their use is now growing swiftly in the UK and many of the export markets we operate in around the world.”

“Their benefits are numerous but key is the fact that they have extremely long lifespans meaning the cleats can be used practically anywhere, including in extremely harsh environments.”

The reason for Solus’ extremely long lifespan is that the glass filled nylon material used is a high-grade engineering polymer. The new range of cable clamps is also fully stackable, meaning additions to cable runs can be made without having to disturb any cables already installed. Solus also features different mounting options that enhance its installation versatility; and because the product can accommodate a wide cable range, customers can stock small numbers of units to cover a wide range of cable sizes.

“Innovation is very much at the heart of everything we do, and Solus is the latest in a long line of new and improved cable management products to have come out the Ellis Patents Innovation Hub here in Rillington,” added Danny.

Key to Ellis’ ability to innovate is its ability to take products from initial ideas through to IEC61914:2015 compliant products; with its in-house Innovation Hub incorporating 3D printers, FEA analysis and a fully equipped testing laboratory. Ellis Patents | Stockists & Distributors

Solus Single Cable Clamps

Specification

Ellis Solus Single Cable Clamps – Dimensions

Ellis Solus Part Number	SL25-38GFN	SL36-52GFN	SL49-75GFN
Cable Range Min ∅ (mm)	25	36	49
Cable Range Max ∅ (mm)	38	52	75
Liner Size (mm)	3	3	3
Cable Range with Liner Min ∅ (mm)	19	30	43
Cable Range with Liner Max ∅ (mm)	32	46	69
Dimensions W (mm)	100	116	138
Dimensions H (mm)	80	95	124
Dimensions D (mm)	60	77	77
Dimensions A (mm)	24	24	26
Dimensions P (mm)	60	75	95
Dimensions ∅	M12	M12	M12
Weight (g)	290	370	493
