Flexible Prysmian Afumex Cable

Prysmian Afumex Cable

LS0H H05Z1Z1-F

Prysmian Afumex H05Z1Z1-F is a Low Smoke Zero Halogen Cable which reduces the hazards caused by fire and ensures the fire does not get worse – meets the new improved flexing requirements of BS EN 50525-1 section 7.4 annex A.

AFFLEX Afumex H05Z1Z1-F cables are packed with features that make it the ideal solution for final connection into a device or luminaire in public buildings.

Prysmian Afflex Cable



Prysmian Afumex H05Z1Z1-F Cable

Features

Cable Approvals : HAR approved AENOR: EN 50525-3-11

AFFLEX Afumex

Conductor : Stranded copper class 5 according to IEC 60228

Insulation : Thermoplastic compound LSOH, type TI 6

Separator : Easy strip tape to ensure quick and effortless sheath removal

Outer Sheath : White Thermoplastic compound, LSOH, type TM 7

Core Identification : o Brown o Blue, o Brown o Blue o Green/Yellow, o Brown o Black o Grey o Green/Yellow or o Brown o Black o Grey o Blue o Green/Yellow

Fire Performance :

> Flame retardant: UNE EN 60332-1-2, IEC 60332-1-2
> Fire retardant: UNE EN 60332-3-24, IEC 60332-3-24
> Zero Halogen: UNE EN 50267-2-1, IEC 60754-1
> Low Smoke: UNE EN 61034-2, IEC 61034-2
> Acidic and corrosive gases: UNE EN 50267-2-2, IEC 60754-2

AFFLEX LSOH H05Z1Z1-F Cable

Features

  • Reference Standards EN 50525-3-11
  • Service temperature -10 + 70 °C
  • Rated voltage 300/500 V
  • AC Voltage test, 5 min at 2.0kV
  • Bending radius 4D
  • Genuine FLEX (EN 50525-1)
  • Easy strip sheath: no sticking or jamming
  • Genuine low smoke, zero halogen and flame retardant

H05Z1Z1-F Cable SPECIFICATION

Nominal cross sectional area mm² Insulation
Thickness
mm
Nominal
Outer
Sheath
Thickness
mm
Approx.
Outer
Diameter
mm
Approx.
Weight
kg/km
Prysmian
Code
Two Core
0.75 0.6 0.8 6.5 60 20163901
1.0 0.6 0.8 6.7 65 20163874
Three Core
0.75 0.6 0.8 6.8 70 20163902
1.0 0.6 0.8 7.1 78 20163875
1.5 0.7 0.9 8.3 107 20163876
2.5 0.8 1.1 10.1 167 20163880
4.0 0.8 1.2 11.3 227 20163881
Four Core
0.75 0.6 0.8 7.4 84 20163903
1.0 0.6 0.9 7.9 98 20163877
1.5 0.7 1.0 9.3 135 20163878
2.5 0.8 1.1 11.1 203 20163879
4.0 0.8 1.2 12.4 278 20163882
Five Core
0.75 0.6 0.9 8.3 103 20163904

➡ See Prysmian for a complete range of LV-HV cable accessories including joints, glands, cleats and cable terminations for use with Afumex cables.




Afumex | Low Smoke Cables

Afumex cables are low smoke high performance and flame retardant electrical cables for power and control cables – the cable sheath is LSOH (Low Smoke Zero Halogen) which the event of a fire will emit very low levels of smoke and non-toxic levels of poisonous halogen gases.

  • Low Smoke: meets BS EN 61034-2
  • Zero Halogen: meets BS EN 60754-1
  • Flame Retardant: meets BS EN 60332-1-2 or BS EN 60332-3-24
  • Fully approved: BASEC approved to BS EN 50525-3-41, BS7211, BS6724 or BS8436
