Split Connectors
Sicon
Split connectors, from the SICON range manufactured by Pfisterer, can be used in LV MV HV cable installations where it is difficult to install the connector on the conductor.
The connector comes apart in 2 pieces and allows easy installation by the cable jointer or installer. The 2 pieces of the connectors are then bolted together in the middle to form one connector again. Typical applications for split connectors are for use with PILC to PILC 3 core cable joints and any tight spot where it is difficult to bend the cable.
âž¡ More information about Shearbolt Cable Connectors & Cable Lugs
♦ Also available: Branch Connectors | Cable Lugs Central Palm | Cable Lugs NEMA
Contact Thorne & Derrick for competitive delivery from stock for the complete range of Pfisterer products including Electrical Safety Equipment and CONNEX plug-in cable connectors for the termination of cables into transformers and gas insulated switchgear.
Split Connectors
Product Selection Guide
| Connector Range (kcmil) | L (inch) | OD (inch) | I (inch) | H (inch) | Z (inch) | Connector Range (mm²) | L (mm) | OD (mm) | I (mm) | H (mm) | z (mm) | Hex Size | Part No (Al + Cu) |
| Bolted Connector (MC-OS) | |||||||||||||
| #7-3/0 AWG | 2.32 | 0.94 | 10-95 | 59 | 24 | 5 | 332 601 012 | ||||||
| #5-300 | 3.50 | 1.1 | 16-150 | 89 | 28 | 5 | 332 593 012 | ||||||
| 1/0-500 | 4.41 | 1.30 | 50-240 | 112 | 33 | 6 | 332 592 012 | ||||||
| 1/0-500 sector | 4.41 | 1.38 | 50-240 sector | 112 | 35 | 6 | 332 614 012 | ||||||
| 1/0-600 | 4.88 | 1.38 | 50 – 300 | 124 | 35 | 6 | 332 602 012 | ||||||
| 3/0-600 | 5.20 | 1.50 | 95 – 300 | 132 | 38 | 8 | 332 617 012 | ||||||
| 350-800 | 6.73 | 1.65 | 185 -400 | 171 | 42 | 8 | 332 640 012 | ||||||
| 500-1000 | 7.80 | 2.05 | 240 – 500 | 198 | 52 | 8 | 332 640 012 | ||||||
| 600-1250 | 8.19 | 2.05 | 300 – 630 | 208 | 52 | 8 | 332 603 012 | ||||||
