Ellis Patents Cable Cleats for Major Power Plant Project
Published 27 May 2025
21.5.2025
HOLDING POWER by Ellis Patents | 30,000+ Vulcan Cleats and Flexistraps shipped out today under the blazing Yorkshire sun. The cable cleats will provide short-circuit restraint to both 11kV and 33kV Medium Voltage Cable Networks.
This WIN demonstrates the high-value of collaborative, proactive and strategized Manufacturer-Distributor relationships; we look forward to co-creating a Case Study to highlight how together we have worked to secure this achievement and satisfy clients specification and technical application requirements.
The consignment is now to be delivered to SEB International Ltd, the UK’s leading manufacturer of Cable Pulling & Laying Equipment, and consolidated for shipment with a CD500S Cable Drum Trailer (Payload 20,000kgs | Max Drum Width 2400mm), TW5000 Cable Pulling Winch and CP700 Cable Pushing Unit to power-up an accelerated cable laying process.
The £750K project value to Thorne & Derrick demonstrates our ability to manage and deliver upon UK and international major projects from our robust world-class supply-chain.
The High Voltage 132kV Cables will be connected to Grid using GIS Dry-Type Terminations from Nexans while all Medium Voltage 33/11kV switchgear and transformer Connectors are completed using market-leading Euromold and Connex brands from Nexans Power Accessories and Pfisterer.
All Cleats & Cable Accessories supplied by Thorne & Derrick – the purchase contract was managed by Gary Amos (Thorne & Derrick Sales Engineer).

Ellis Patents | HOLDING POWER
Pictured | Carl Cox (Thorne & Derrick Sales Engineer | Rail) with Noman Shabir (Ellis Patents National Sales Manager). The Ellis Patents ranges of PADS Approved Cable Cleats & Tunnel Hangers provide advanced material performance for substation, trackside and tunnel applications; this includes the short-circuit restraint and support of LV MV HV power cables. Please do not hesitate to contact Thorne & Derrick should you require further info, Lunch n Learn, CPD or Joint Visit to discuss your next cable cleat project requirements.

Ellis Patents Emperor Cable Cleats | Single & Trefoil | cable cleats designed, developed, tested and manufactured by Ellis from the Emperor range in accordance with IEC 61914 suitable for single, trefoil and Quad cable configurations

Ellis Patents Centaur Cable Saddles | the Ellis Centaur cable cleat has been designed, developed, tested and manufactured in accordance with IEC 61914 (Cable Cleats for Electrical Installations). The cable saddles are designed to support High Voltage Power Cables with diameters from 100mm to 162mm. Centaur consists of an extruded and pressed aluminium saddle and a hinged aluminium over strap.

Ellis Patents Aluminium Cable Cleats | the Ellis 2A two hole cable clamps have been designed, developed, tested and manufactured in accordance with IEC 61914 (Cable Cleats for Electrical Installations). The cable clamps are available in a range of sizes with range taking ability to suit single cables – the clamp can be epoxy coated for use in harsh environments, such as sea air conditions.

Ellis Patents Vulcan Cable Cleats | the Vulcan cleats are available in a range of sizes with range taking ability to suit single and trefoil cable formations (also available in Quad formation). The frame of the cleat is manufactured from corrosion-resistant 316L grade stainless steel, the cable is supported by a liner manufactured from a low smoke zero halogen (LSOH) material.

Ellis Patents Colossus Cable Cleats | The Colossus cleat is available in a range of sizes with range taking ability to suit LV MV HV cables in trefoil formation. The frame of the cleat is manufactured from grade 316L stainless steel, and the body of the cable cleat is manufactured from a low smoke and zero halogen (LSOH) material.

Ellis Patents Trident Cable Cleats | cable cleat is available in a range of sizes with range taking ability to suit LV MV HV cables in trefoil formation. The cleat is manufactured as standard in LSF which is PFAS and halogen free, flame retardant and suitable for outdoor applications.
