What Are BAND-FAST Cable Clamps?

BAND-FAST is ready to use stainless steel strapping and cable banding which is pre-cut and pre-assembled with a buckle. The pre-assembled cable clamp gives you an edge over your competition as it saves up to 30% time and labour costs for your large LV-HV cable installation projects.

BAND-FAST cable clamps manufactured by BAND-IT, the market-leading supplier of stainless steel cable ties, are a low cost alternative to cable cleats.

Two options are available: a PPA coated version and an uncoated version with captive clip both manufactured from type 316 stainless steel. The BAND-FAST cable clamps are quicker to install reducing labour costs and do not require any additional cable fixings to provide cable containment and short circuit restraint to LV, MV & HV Power Cables.

The cable clamps have successfully been utilised on the following applications:

  • Offshore Platforms / FPSO’s
  • Shipbuilding
  • Refineries / Petrochem
  • Public Buildings
  • Electromechanical Force Testing

BAND-FAST cable clamps are also available in different materials including:  Monel®, Inconel®, AL6XN®, Titanium, 316 Stainless Steel – specified for both onshore, offshore and subsea cable support and strapping in industrial and hazardous area locations.

BAND-FAST cable clamps

Advantages

  • Purchase price is significantly lower

–Up to 75% material cost savings

  • Installation time is dramatically reduced

–Reduce labour cost by over 50%

  • Lower profile

–Space savings on construction

  • More versatile

–Conforms to most shapes / cable configurations

–Fewer SKU’s to order / stock

  • Large diameter reduction (one size fits all)

–Fewer SKU’s to order / stock

  • No accessories required

–No nuts / bolts / packing blocks

  • Lighter weight cable clamps

–Reduced weight on construction

–Easier to carry around site

–Safer during installation at height

Cable Cleat Standard IEC61914:2015

The cable clamps are independently tested to the latest Cable Cleat Standard IEC61914:2015 for resistance to electromechanical force.

Short Circuit Testing of BAND-FAST Clamps

Short Circuit Testing of BAND-FAST Clamps

Tests conducted to IEC61914:2015

“Tests for Resistance to Electromechanical Force” Section 6.4.3 and 6.4.4.

➡ The following tables enables the selection of the correct BAND-FAST cable clamp manufactured by BAND-IT inclusive of recommended clamp spacing to achieve sufficient short-circuit protection according to IEC61914.

BAND-FAST™  Cable Clamp Ref BAND-IT Ref Buckle / Clip Ref Description Strap Width Single or Double Wrap Spacing Between Clamps Cat 1 (Clause 9.5.2*) Pass level kA peak Test Report  # (Test Video  #) Cat 2 (Clause 9.5.3**) Pass level kA peak Test Report  # (Test Video  #)
LFAC-F1015M***-A900 AE435 AE455 PPA Coated 5/8” Single 300mm (12”) 50.8 kA PDL-17.003.2 (4) 40.9 kA PLD-17.003.1        (2 & 3)
LFFC-F1015M***-A900 AE435 LE155 PPA Coated 5/8” Double 300mm (12”) 76.3 kA PLD-17.003.3
(6 & 7)
LFEC-F1030M*** C405 C455 Uncoated with channel 5/8” Double 300mm (12”) 110 kA PLD-17.003.4(13 & 14)
LFEC-F1230M*** C406 C456 Uncoated with channel ¾” Double 300mm (12”) 120 kA PLD-17.003.5 (17)
LFFC-F0815M***-A900 AE434 AE454 PPA Coated ½” Double 600mm (24”) 45.1 kA PLD-17.003.9(36 & 37)
LFAC-F1015M***-A900 AE435 AE455 PPA Coated 5/8” Single 600mm (24”) 45.5 kA PLD-17.003.6(26 & 27)
LFFC-F1015M***-A900 AE435 LE155 PPA Coated 5/8” Double 600mm (24”) 70.1 kA PLD-17.003.7(32 & 33)
LFEC-F1030M*** C405 C455 Uncoated with channel 5/8” Double 600mm (24”) 112 kA PLD-17.003.8(44 & 45)



Subjected to 2x Short Circuits and dielectric test after wetting

Subjected to 2x Short Circuits and dielectric test after wetting

PPA Coated BAND-FAST Cable Clamps By BAND-IT

BAND-IT Part Number Width Band Ref/Material Length (mm) Clip/Ref Material  Single Wrap or Double Wrap *Max Cable OD (Single cable config) *Max Cable OD (Trefoil cable config) *Max Cable OD (Quadrafoil cable config) Pack qty Piece Weight Per Piece (kg) **Pass IEC61914:2015 Short circuit test in trefoil up to (KA PEAK)
LFAC-F1015M030–A900 15.88mm (5/8”) AE435
316 SS
300 AE455
316 SS
Single 40mm 13mm 12mm 100 0.025 50.8kA
LFAC-F1015M040–A900 400 75mm 28mm 25mm 100 0.030
LFAC-F1015M050–A900 500 100mm 43mm 37mm 100 0.038
LFAC-F1015M060–A900 600 130mm 57mm 50mm 100 0.045
LFAC-F1015M070–A900 700 160mm 70mm 60mm 100 0.052
LFFC-F1015M040–A900 400 LE155
316 SS
1Double 40mm 13mm 12mm 100 0.030 76.3kA
LFFC-F1015M050–A900 500 55mm 21mm 18mm 100 0.038
LFFC-F1015M060–A900 600 70mm 28mm 25mm 100 0.045
LFFC-F1015M070–A900 700 85mm 35mm 31mm 100 0.052
LFFC-F1015M080–A900 800 100mm 42mm 37mm 100 0.060
LFFC-F1015M100–A900 1000 130mm 57mm 50mm 100 0.075
LFFC-F1015M120–A900 1200 160mm 70mm 60mm 100 0.090
Ref C075 Bantam Tool for application of all PPA Coated BAND-FAST® Clamps 1.040

Uncoated BAND-FAST Cable Clamps installed with additional cushion sleeve

BAND-IT Part Number Width Band Ref/Material Length (mm) Clip/Ref Material  Single Wrap or Double Wrap *Max Cable OD (Single cable config) *Max Cable OD (Trefoil cable config) *Max Cable OD (Quadrafoil cable config) Pack qty Piece Weight Per Piece (kg) **Pass IEC61914:2015 Short circuit test in trefoil up to (KA PEAK)
LFEC-F1030M050 15.88mm (5/8”) C405
316 SS
500 C455
316 SS
Double 55mm 21mm 18mm 100 0.062 112kA
LFEC-F1030M060 600 70mm 28mm 25mm 100 0.070
LFEC-F1030M070 700 85mm 35mm 31mm 100 0.078
LFEC-F1030M080 800 100mm 42mm 37mm 100 0.086
LFEC-F1030M100 1000 130mm 57mm 50mm 100 0.103
LFEC-F1030M120 1200 160mm 70mm 60mm 100 0.120
LFEC-F1230M050 19.1mm (3/4″) C406
316 SS
500 C456
316 SS
Double 55mm 21mm 18mm 100 0.078 120kA
LFEC-F1230M060 600 70mm 28mm 25mm 100 0.088
LFEC-F1230M070 700 85mm 35mm 31mm 100 0.098
LFEC-F1230M080 800 100mm 42mm 37mm 100 0.108
LFEC-F1230M100 1000 130mm 57mm 50mm 100 0.128
LFEC-F1230M120 1200 160mm 70mm 60mm 100 0.150
Ref C001 Band-It® Tool for application of all Uncoated BAND-FAST® Clamps 2.000

*Note: Maximum cable OD are for a guide only.

Short Circuit Test Videos

PPA Coated BAND-FAST® Cable Clamps with Clip. Test Video #33 70.1kA (second shock).

Uncoated BAND-FAST® Cable Clamps with E/L Buckle and Rubber Channel. Test Video #45 110kA (second shock).
