E1WF-AL Cable Glands - Hazardous Area Exd IIC Ex e II (Prysmian 455AA)

E1WF-AL Cable Glands – Flameproof Ex e/Ex d & Explosion Proof

E1WF-AL Cable Glands from the Prysmian 455AA range of hazardous area cable glands suitable for terminating circular aluminium wire armoured cables in Zone 1 and Zone 2 locations – Prysmian E1WF-AL cable glands provide high performance in high temperatures and achieves IP66 seal onto cable and to enclosure with suitable sealing washer or thread sealant.

E1WF-AL Cable Glands – Prysmian 455AA

Flameproof Ex e/Ex d Cable Glands & Kits
  • E1WF-AL aluminium indoor and outdoor hazardous area cable gland
  • Suitable for circular armoured cables with extruded cable with extruded polymeric bedding and oversheath
  • Achieves IP66 seal onto cable and to enclosure with suitable sealing washer or thread sealant
  • Weatherproof & waterproof cable gland
  • Cable glands certified to II 2GD, Ex e II & Ex d IIC under ATEX directive 94/9/EC
  • Inner PCP seal grips cable bedding and provides additional ingress protection
  • Three part armour lock provides mechanical cable retention and electrical continuity
  • Service temperature range -60°C to +90°C
  • ATEX Compliance Standards: EN 60079-0, EN 60079-1, EN 60079-7, EN 61241-0, EN 61241-1
  • IECEx Compliance Standards: IEC 60079-0, IEC 60079-1, IEC 60079-7, IEC 61241-0, IEC 61241-1

➡ MV-HV Cables. Medium voltage and high voltage cable glands for high fault current carrying capacity applications are available – visit medium voltage cables for 6.6kV, 11kV and 33kV cable specifications.

Hazardous Area E1wF-AL Cable Glands

PRYSMIAN 455AA

Hazardous Area Zone 1 Zone 2 Cable Glands

E1WF-AL cable glands are suitable for use in:

  • Zones 0, 1 & 2 with Ex ia IIA, B & C Equipment
  • Zones 1 & 2 with Ex ib IIA, B & C Equipment
  • Zones 1 & 2 with Ex e II Equipment
  • Zone 2 with Ex nA II Equipment
  • Zones 21 & 22 with Ex tD II Equipment

Additionally, where the cable is effectively filled, the E1WF-AL cable glands can be used in:

  • Zones 1 & 2 with Ex d IIC Equipment not containing a source of ignition and volume less than 2000cm³
  • Zones 1 & 2 with Ex d IIA & Ex d IIB Equipment not containing a source of ignition/volume
  • Zone 1 with Ex d IIA & Ex d IIB Equipment containing a source of ignition and volume less than 2000cm³
  • Zone 2 with Ex d IIA & Ex d IIB Equipment containing a source of ignition and with any volume
  • Zone 2 with Ex nR II Equipment

ATEX E1WF-AL Cable Glands

ATEX Certified Cable Gland II 2GD, Ex e II & Ex d IIC.



Hazardous Cable Glands Prysmian

Cables & Accessories for Hazardous Areas

T&D also distribute Prysmian Draka Offshore Cables for LV-HV power, control and instrumentation – flameproof hazardous area cable joints, cable cleats and cable transit sealing systems for low, medium and high voltage cables. See also: Prysmian Cable Cleats

Prysmian Bicon Cable Gland Reference Cable Gland Size Cable Dimensions (mm) 455AA Cable Gland Dimensions (mm)
Under Armour Ø (A) Overall Ø (B) Armour Wire Ø Entry Thread (D) Thread Length (E) Protrusion Length (F) Hexagon
Standard Min Max Min Max A/F (G) A/C (H)
455AA-51 16 3.8 8.7 8.0 13.2 0.9 M16×1.5 15 41 23.4 26.7
455AA-71 20SS 3.8 8.7 8.0 13.2 0.9 M20×1.5 15 41 23.4 26.7
455AA-52 20S 8.0 11.8 8.0 15.8 0.9 /1.25 M20×1.5 15 43 25.7 29.2
455AA–53 20 11.8 14.2 11.7 20.8 0.9 /1.25 M20×1.5 15 43 30.5 34.0
455AA–55 25 14.0 20.1 17.0 27.2 1.25 / 1.6 M25×1.5 15 48 37.6 42.2
455AA–56 32 19.7 26.6 23.5 33.5 1.6 / 2.0 M32×1.5 15 53 47.2 53.6
455AA–57 40 26.6 32.4 29.0 39.9 1.6 / 2.0 M40×1.5 15 56 56.4 61.5
455AA-58 50S 32.4 38.4 38.0 46.2 2.0 / 2.5 M50×1.5 15 61 60.0 66.0
455AA–59 50 38.4 44.3 39.5 52.6 2.0 / 2.5 M50×1.5 15 61 70.1 77.2
455AA–60 63S 44.3 50.3 50.0 58.9 2.5 M63×1.5 15 64 75.0 83.0
455AA–61 63 50.3 56.2 51.3 65.3 2.5 M63×1.5 15 64 80.0 87.4
455AA–62 75S 56.2 62.2 62.0 71.6 2.5 M75x1.5 15 73 90.2 99.1
455AA–63 75 62.2 68.1 62.5 78.0 2.5 M75x1.5 15 73 98.8 109.2
455AA–64 85 68.0 74.0 68.0 88.0 3.15 M85x1.5 20 102 115.1 126.0
