A2EXP75 (NPT) Hazardous Area Cable Glands – Prysmian 495NE-45

A2EX Cable Glands – Hazardous Area Exd IIC / Ex e II (Prysmian 494AB)

A2EXP75 (NPT) Hazardous Area Cable Glands

Prysmian 495NE-45 (A2EXP75) A2EXP hazardous area cable glands are certified ΙΙ 2GD, Ex e ΙΙ & Ex d ΙΙC under ATEX directive 94/9/EC suitable for circular unarmoured cables with extruded oversheath providing high performance in high temperatures in deluge and IP68 conditions.

Prysmian 495NE-45 are suitable for most climatic conditions – weatherproof, waterproof and deluge proof and have a service temperature range –50°C to +200°C.

Prysmian A2EXP75

Hazardous Area Cable Glands

Technical Specification

ATEX Cable Glands

Manufacturer: Prysmian
Brand: Bicon
Order Code: 495NE-45 (A2EXP75)
Cable Gland Size: A2EXP75
Cable Dimensions Ø (B): Min 54.5mm Max 65.5mm
Entry Thread (D) : 3” NPT
Thread Length (E) : 33.5mm
Protrusion Length (F): 120mm
Hexagon A/F (G): 98.8mm
Hexagon A/C (H): 109.2mm
Nickel Plated Version: Prysmian 495NE-45V (A2EXP75)
