Polypipe Ridgiduct Street Lighting Cable Duct

Polypipe Ridgiduct Street Lighting Cable Duct

Polypipe Ridgiduct Street Lighting Cable Duct

Polypipe Ridgiduct street lighting cable duct provides a durable, lightweight and flexible twinwall cable protection and is used for street lighting and traffic signal applications.

Street lighting cable duct is available in three inner diameter sizes of 94mm, 100mm and 150mm and in lengths of 6 metres.

The cable duct is manufactured from high density polyethylene (HDPE) and is supplied with a black polypropylene (PP) coupler.

Polypipe street lighting cable duct has a static coefficient of less than 0.22 and adequate resistance to attack from chemicals which are likely to occur in soils and ground water – also available in Ridgicoil flexible coil ducting as well as straight lengths.

T&D offer a full range of Street Lighting Cable Duct, contact us for further information.

BBA Approved Cable Duct

BBA Approved Cable DuctPolypipe’s Ridgiduct street lighting cable duct is a BBA approved cable duct system.

BBA is the British Board of Agrément which issues certificates for construction products and systems and provides inspection services.

Ridgiduct street lighting cable duct was assessed by the BBA to ensure sufficient resistance to chemicals and confirmed elevated temperatures were achieved and the ducting provided adequate durability and strength. T&D also offer a full range of products for street lighting applications such as cut outs and isolators.

Polypipe Ridgiduct Street Lighting Cable Duct

T&D distribute an extensive range of Street Lighting Equipment, including Lucy Zodion feeder pillars

Polypipe Ridgiduct Street Lighting Cable Duct

Features & Benefits

  • Cable duct complies with BS EN 61386-24:2010, Type 450N, normal duty impact resistance
  • BBA and BBA HAPAS approved
  • Network Rail PADS approved cable duct
  • Good impact resistance, even at low temperatures
  • Flexible in application, with a minimal requirement for special bends
  • Available with print options for street lighting and traffic signals
  • Supplied with an integral coupler
  • Low weight, flexible, durable and high strength
  • Polypipe Ridgicoil Street Lighting Cable Duct

Ridgiduct Street Lighting Cable Duct – Product Range

Polypipe Ridgiduct Cable Duct Product Code Inner Duct Diameter (mm) Outer Duct Diameter (mm) Length (m) Pack Quantity
RB94X6O (SL or TS) 94mm 110mm 6m 95
RB100X6O (SL or TS) 100mm 118mm 6m 85
RB150X6O (SL or TS) 150mm 178mm 6m 36

Available with street lighting (SL) or traffic signal (TS) print.

Cable Duct Joints & Long Radius Drawn Bends

Polypipe Ridgiduct Long Radius Drawn Bends
Inner Diameter
Bend Radius (mm)
Angle º
Coupler Codes
Pack Quantity
94mm 420mm 11.25º RBDB94X11X0.42 10
420mm 22.5º RBDB94X22X0.42 10
420mm 45º RBDB94X45X0.42 7
420mm 90º RBDB94X90X0.42 7
100mm 420mm 11.25º RBDB100X11X0.42 10
420mm 22.5º RBDB100X22X0.42 10
420mm 45º RBDB100X45X0.42 7
420mm 90º RBDB100X90X0.42 7
150mm 610mm 11.25º RBDB150X11X0.61 5
610mm 22.5º RBDB150X22X0.61 5
610mm 45º RBDB150X45X0.61 4
610mm 90º RBDB150X90X0.61 3
Cable Duct Jointing
Inner Diameter Coupling Code Sealed System Code*
94mm RBC94 CRD94 & SRD 94/1
100mm RBC100 CRD100 & SRD100
150mm RBC150 CRD150 & SRD150

*1 coupler and 2 seals per joint. Bends are supplied in the colour black only.

Cable Ducts
Cable Duct

T&D distribute cable duct for power (LV MV HV), street lighting and motorway communications – Class 1, 2 & 3 ducts protect medium/high voltage cables operating at 11kV, 33kV and EHV up to 132kV.
