MV HV Substation Electrical Safety Kits
The MV HV Substation Electrical Safety Kits designed by PENTA to assist people in the presence of electrical hazards, up to 25kV medium voltage networks with the VES25 model or up to 36kV high voltage networks with the VES36 model (also available as LV Substation Rescue & Intervention Electrical Safety Kits). PENTA’s electrical safety kits provide life saving rescue and intervention in the event of an electrical based incidents in and around MV HV substations and whilst working on electrical installations. The kit is particularly suitable for incidents such as on-road, electric and hybrid vehicles, cable removal, work on photovoltaic panels, work on electrified railways and in general electrical industries.
The MV HV Substation Rescue & Intervention Safety Kits is compact with a range of MV and HV electrical safety equipment, such as insulating stools, insulating gloves, insulating boots & sticks, a voltage detector with integrated self-testing (voltages of 127V AC to 90kV), a 36kV cable cutter and more. Useable for indoor and outdoor scenarios.
penta RESCUE & INTERVENTION electrical Safety Kits Specifications
MV HV Electrical Safety Kit Voltage Detector
Kit Contents MV HV | PENTA VES 25kV 36kV Substation Electrical Safety
- Electrical Insulating stool: 25kV or 36kV models available
- Electrical Insulating gloves: GLB3-36-10 (class 3) for model PENTA VES25 or GLB4-41-10 (class 4) for model VES36
- Electrical Insulating boots (TB19): protection against step voltage (voltage gradient in the ground)
- Telescopic Insulating stick (PPOLVES) equipped with a hook (CSVES): telescopic stick with pentagonal shape for a perfect grip
- Voltage detector (TDPESEC): detects all voltages of 127 V AC and above (does not detect DC voltages), with automatic wake up when voltage detected
- Cable cutter (CCIVES): Insulated 36kV cable cutter
- Talc shaker (TS10T): for easier donning of gloves
- Fabric case for gloves (TS10): mechanical and UV protection
- Adhesive maker tape (S174JN): for marking off an area, preventing a disconnect switch from being reset, etc
- Instruction for use (VESNOT): in diagram form for quick reading and guidance
WALL-MOUNTED RESCUE Kits Benefits
MV HV Rescue & Intervention Electrical Safety Kits Functionality – Penta
An Electrical Safety Kit for Field Operations
- Compact: For storage efficiency in vehicles, the case is 600 x 400 x 310 mm in size
- Mobility: Exclusive wheel system and handle to facilitate ease of access to the intervention area
- Tough: The materials and the manufacturing process have been selected to give the case optimum service life
- High Visibility: Retro reflective strips are used for greater visibility
- Optimised Storage: The case packs a lot of equipment efficiently into a small space
PENTA VES SUBSTATION ELECTRICAL SAFETY KITS SELECTION GUIDE
MV HV Rescue & Intervention Electrical Safety Kits 25kV 36kV
The following table includes further insight on the Rescue & Intervention Safety Kit nationality variants for the MV HV Substation Electrical Safety Kits product:
| MV HV Substation Electrical Safety Kits Product Reference | Max Operating Voltage | Description | Product Particularities |
| PENTA VES25 | 25kV | 25kV electro-emergency case | 25kV stool and gloves class 3 |
| PENTA VES36 | 36kV | 36kV electro-emergency case | 36kV stool and gloves class 4 |
