Arc Flash GORE-TEX PYRAD Hi-Vis Yellow Stretch Trousers 30 Cal (Male)
Arc Flash GORE-TEX PYRAD Hi-Vis Yellow Stretch Trousers 30 Cal (Male)
ARC FLASH CLOTHING
Category 2 GORE-TEX PYRAD WT252M Yellow Stretch Trousers By ProGARM
ProGARM Arc Flash GORE-TEX Stretch Trousers provides Category 2 protection against arc flash with 30cal/cm² according to EN 61482-2:2020 “open arc” test method forming part of the ProGARM range of Arc Flash Clothing.
Should you require guidance on selection and use of an Arc Flash Calculator please call Thorne & Derrick, the UK’s leading specialist distributor of electrical safety equipment for LV (Low Voltage), MV (Medium Voltage) and HV (High Voltage).
The WT252M stretch trousers manufactured by ProGARM are designed for workers to endure long days and changeable weather conditions in the harshest environments whilst offering freedom of movement when bending or stretching. It can be relied on for protection against thermal hazards of an electric arc.
Arc Flash GORE-TEX PYRAD sizes range from 8R-24R,RED LEG (31″/80cm).The Arc Flash Trousers is also available in female sizes quote reference ProGARM WT252F.
Accompanying garments include:
| Arc Flash Clothing Name | Item |
Arc Flash Jackets |
|
Arc Flash Hoods |
|
Arc Flash Protection
- EN 61482-2:2020: APC 2 // ATPV=40 cal/cm² // ELIM=30 cal/cm²
Arc flash GORE-TEX PYRAD Trouser category 2
Features & benefits
- Heat applied FR industrial wash ProGARM HEX Reflective Tape
- Articulated design for improved fit and ergonomics
- FR wide main zip for increased durability
- Inner fleece on the braces to additional comfort
- Internal inspection access for easier repairs
- Two large combat bellow pockets featuring grab tabs for easier
- opening and closing when wearing gloves
- Elasticated waist for better fit
- Reinforced knee area with special highly abrasion resistant fabric
- External kneepad pocket
- Removable braces
- Ladderlock braces adjustment for easier and quicker donning
- Wide belt loops to avoid belt riding up
- Ankle hook and loop adjustment
- Long leg zips for easier donning and doffing
- FR heat applied SafetyICON for wearer awareness
See full range of Arc Flash Clothing, PPE & Protection Garments
HI-VIS YELLOW JACKET 30 CAL
tECHNICAL SPECIFICATION
- Size: Small / Medium / Large / XLarge / 2XLarge / 3XLarge / 4XLarge
- Colour: Hi-Viz Yellow/Navy
- Gender: Male
- Open ARC Test: ATPV=40 cal/cm² ELIM=30 cal/cm²
- Box Test: APC 2
- Protection Type: ARC Flash / Hi-Vizibility / Railway
- EN Standard: EN 61482 / EN 343 / EN 1149 / EN 13034 / EN ISO 11611 / EN ISO 11612 / EN ISO 20471 / RIS-3279-TOM
- Fabric: GORE-TEX Pyrad ® STRETCH
- Industry Sector: Industrial Electrical / Rail / Utilities & Power Generation
- Type: Arc Flash Jackets
European Standards
ProGARM WT252M arc flash stretch trousers conform to the following European Standards:
- EN 61482-2:2020: APC 2 // ATPV=40 cal/cm² // ELIM=30 cal/cm²
- EN ISO 11612:2015: A1 // B2 // C2 // F1
- EN ISO 11611:2015: Class 2 // A1
- EN 343:2019 // Class 4/4/x
- EN 13034:2005: Type 6 +AI:2009
- EN 1149-5:2008: Pt. 5:2018 // Pt. 3:2004 // Charge Decay
- EN ISO 20471:2013: Class 3 Jacket Class 1 Trouser
Stretch Jacket | Care Information
ProGARM WT252M arc flash stretch trousers must be carefully cleaned to ensure arc flash protection levels are maintained.
- Maximum washing temp 60°C
- Do not bleach
- Tumble dry, low temperature
- Iron, high temperature
- Dry cleaning permittable
Arc flash stretch trousers size chart
IEC Standard 61482 – Class 1
Garment Category – Trousers
Order Code – ProGARM WT252M
| UK Size | 8R | 10R | 12R | 14R | 16R | 18R | 20R | 22R | 24R |
| WAIST TO FIT (INCHES) | 30.7 | 32.7 | 34.6 | 36.6 | 38.6 | 40.6 | 42.5 | 44.5 | 46.5 |
| WAIST TO FIT (CMS) | 78 | 83 | 88 | 93 | 98 | 103 | 108 | 113 | 118 |
| HIPS TO FIT (INCHES) | 40.6 | 42.5 | 44.5 | 46.5 | 48.4 | 50.4 | 52.4 | 54.3 | 56.3 |
| HIPS TO FIT (CMS) | 103 | 108 | 113 | 118 | 123 | 128 | 133 | 138 | 143 |
| INSIDE LEG TO FIT (INCHES) | 29.5 | 29.5 | 29.5 | 29.5 | 29.5 | 29.5 | 29.5 | 29.5 | 29.5 |
| INSIDE LEG TO FIT (CMS) | 75 | 75 | 75 | 75 | 75 | 75 | 75 | 75 | 75 |
IEC 61482 PROTECTIVE CLOTHING AGAINST THE THERMAL HAZARDS OF AN ELECTRIC ARC
Arc flash clothing and garments in a layered combination deliver workwear protection against hazards according to IEC 61482 – PPE protects the worker against electric arc flash dangers. According to IEC 61482-1-1:2009 (encompassing NFPA 70E 2015) the 4 arc risk categories are numbered according to the severity threat and determine the clothing protection level required to protect against a minimum level of incident energy measured in calories / cm² – this is the ‘Open Arc’ test method and measures clothing protection level according to the Arc Thermal Performance Value (ATPV).
NFPA 70E outlines the requirements for safe work practices to protect personnel by reducing exposure to workplace electrical hazards.
Electrical PPE Products | Gloves | Arc Flash Clothing | Arc Suits | Coveralls | Helmets & Visors
Safety Wear & Arc Flash Protection | Thorne & Derrick understand how critical it is to have reliable, highest quality personal protection equipment (PPE), clothing and workwear available from stock at competitive prices – protecting utility workers against arc flash dangers posed during maintenance on underground electric cables, overhead line conductors or electrical equipment
Datasheet – Arc Flash GORE-TEX PYRAD Hi-Vis Yellow Stretch Trousers 30 Cal M+FDownload
