Cable Boxes | Termination of Medium & High Voltage Cables
Thorne & Derrick supply standard and customised cable boxes to protect cable terminations operating at 11kV – 33kV voltages to provide protection of medium/high voltage cable-end terminations including heat shrink, cold shrink and separable connector types.
Webster Wilkinson cable boxes are designed for the dry termination of HV cables – suitable for protecting MV-HV cable terminations at 11kV – 33kV voltages with XLPE or PILC type insulation.
Plug-in fully insulated cable boxes they must have MV HV bushings for use with separable connectors.
Plug In Separable Connector Cable Boxes 11kV 24kV 33kV
♦ Related MV Electrical Equipment | Surge Arresters MV HV | Fuses MV HV | Surge Diverters | Portable Earthing | Electrical Safety
Cable Boxes Fully Insulated  11kV 24kV 33kV
15/25kV 800/1250A High Voltage Cable Box
| Poles | Cable Glands | Flange | Interface | Drawing |
| 3 | 3/6/9/12 | E | D Bolted | C8412 |
12/24/36kV 400A High Voltage Cable Box
| Poles | Cable Glands | Flange | Interface | Drawing |
| 3 | 3/6/9/12 | H | B Sliding | C8737 |
12/24kV 250A High Voltage Cable Box (125kV BIL)
| Poles | Cable Glands | Flange | Interface | Drawing |
| 3 | 3/6/9/12 | E | A Sliding | C8788 |
24/36kV 400A High Voltage Cable Box
| Poles | Cable Glands | Flange | Interface | Drawing |
| 3 | 3/6/9/12 | E | B Sliding | C8788 |
*Form:Â C- Conventional cube shaped enclosure T- Triangular form for compound filling
11kV 33kV Cable Boxes
- Cable Boxes 11kV 24kV 33kV Â – Transformer Oil / Guroflex Filled Fully Insulated
- Cable Boxes 11kV 24kV 33kV Â – Heat Shrink HV Cable Termination
- Cable Boxes 11kV 24kV 33kV Â –Â Air Insulated Dry HV Cable Termination
Cable Terminations & Connectors For High Voltage Cable Boxes, Switchgear & Transformers
âž¡ Contact T&D for leading brands including Nexans Euromold, 3M Cold Shrink and Pfisterer CONNEX.
T&D supply the most extensive range of MV-HV Joints, Terminations & Connectors to enable the connection of 11kV/33kV cables into cable boxes, switchgear (Gas & Air) and oil transformers – this includes cold shrink, heat shrink and separable connectors.
