FiloShrink Abandonment Kit AK – 2
The Filoshrink AK-range of cable abandonment kits, manufactured by Filoform, are designed for use as a temporary or permanent cable abandonment on Low Voltage LV cables up to and including 3.3kv.
Manufactured from high quality EPDM they are designed for use with XLPE/PVC armoured, non-armoured and Lead Sheathed cables, providing environmental and mechanical protection.
The Filoform Filoshrink cold shrink cable abandonment kits is designed to accommodate single-core, multicore and ship-wiring cables, and requires no specialist tooling or heat source.
All Filoshrink Cold Applied End Caps are designed with a longer body to offer additional moisture protection.
Cold Shrink is cold applied, unlike heat shrink, it does not require a naked flame or heat shrink torch to install for safe use in potentially explosive atmospheres and hazardous area locations.
cold shrink cable abandonment kit
specifications
Filoshrink Cold Shrink Cable Abandonment Kits protect cables, pipes and other cylindrical objects from exposure to moisture, contamination, corrosion, ozone, ultra-violet radiation, physical contact and other environmental hazards.
FiloShrink Abandonment Kit AK – 2 is suitable for applications with a cable diameter of 16.0 > 26.0 mm.
The following table enables the correct selection and specification of cold shrink cable abandonment kit depending upon the cable type:
| Size of conductor | 1 core Armoured | 2 core Armoured | 3 core Armoured | 4 core Armoured | 5 core Armoured |
| 6 mm² | * | – | – | ✔ | * |
| 10 mm² | * | ✔ | ✔ | ✔ | * |
| 16 mm² | * | ✔ | ✔ | ✔ | * |
| 25 mm² | * | ✔ | ✔ | – | * |
| 35 mm² | * | ✔ | – | – | * |
| 50 mm² | ✔ | ✔ | – | – | * |
| 70 mm² | ✔ | – | – | – | * |
| 95 mm² | ✔ | – | – | – | * |
| 120 mm² | ✔ | – | – | – | * |
* POA
Cable abandonment kit Features
- Simple and fast manual installation, no tools required to install Cold Shrink
- Seals cables tight, retains resiliency and pressure even after prolonged years of ageing and exposure
- Water-resistant cable end seals
- No mastic or electrical tapes required
- No torches or heat required
- Resists fungus
- Resists acids and alkalis
- Resists ozone
- Cold Shrink is easily removed
- No training required for installation
