Furse CD086 PVC Covered Aluminium Solid Circular Conductors
PVC Covered Aluminium Solid Circular Conductors
PVC Covered Solid Circular Conductors
Furse cd086
Aluminium is frequently used in the manufacturing of electrical conductors due to it being ductile and relatively resistant to corrosion as well as its low resistance and excellent conductivity, forming part of the Furse range of conductors.
Furse PVC covered aluminium solid circular is available in a range of sizes and colours to meet differing current ratings.
Furse CD086 is a brown PVC covered aluminium solid circular conductor with a diameter of 8 mm.
Furse Product Details
-
Furse Part Number: CD086
- Description: PVC Covered Aluminium Solid Circular Conductor
- Diameter (mm): Ø 8
- Cross-sectional area: 50.27 mm²
- Standard Coil Size: 50 metres
- Copper Weight Per Metre: 0.18 kg
- PVC Cover Colour: BROWN
Aluminium Earthing Standards
- BS EN 755-5 (aluminium)
- BS 5252 (PVC colour)
Furse
With over 125 years of experience Furse provides world leading earthing, lightning and electronic systems protection solutions. From their own designed and manufactured products, through to risk assessment and systems design advice, Furse offers a renowned total solution for Earthing and Lightning Protection.
