Cable Terminations
Nexans AFN are single core cold shrink cable terminations for use indoor/outdoor and specified to terminate medium/high voltage cables in the following voltage classes:
- 6/10 (12) kV
- 6.35/11 (12) kV
- 8.7/15 (17.5) kV
- 12/20 (24) kV
- 12.7/22 (24) kV
- 18/30 (36) kV
- 20.8/36 (42) kV
Slip-on terminations are cold applied terminations require no “hot-working” for safe use in potentially explosive atmospheres and hazardous area locations – the cable terminations are designed for use with polymeric insulated cables (XLPE & EPR). To enable the fault repair, extension, splicing and jointing of existing LV MV HV power cables up to 33kV we also stock a complete range of cold shrink joints.
Slip On Outdoor Cable Terminations 11kV 33kV 42kV Euromold AFN
Outdoor slip-on cold shrink cable termination kit list comprising:
- Cable lug (not included in the standard kit) – crimp lugs or shearbolt lugs are suitable
- Water sealing silicone sleeve
- Silicone housing with sheds and integrated conductive silicone rubber insert providing stress relief for the cable
- Water sealing mastic
- Earthing clamp
- Earthing lug (not included in the standard kit)
Nexans AFN COLD SHRINK TERMINATION SPECIFICATION
The following tables enable the selection of cable terminations using Cold Shrinkable technology manufactured by Nexans:
| Euromold Termination Slip-on Cold Shrink |
Voltage Um (kV) |
Conductor Sizes (sqmm) | |
| min | max | ||
| Nexans AFN 10 | 12kV | 25sqmm | 1200sqmm |
| Nexans AFN 20 | 24kV | 35sqmm | 1200sqmm |
| Nexans AFN 30 | 36kV | 50sqmm | 1000sqmm |
| Nexans AFN 36 | 42kV | 70sqmm | 1000sqmm |
PADS Approved by Network Rail | 25kV Switchgear Terminations
Nexans AFN36-6 42kV single core MV cable terminations are Network Rail PADS Approved – the cold-applied Slip-on cable termination is approved for use with Siemens ASG25 – 25kV air insulated switchgear for AC traction power supply systems.
Nexans AFN selection table
For Indoor MV HV Cable Terminations
Select the Euromold part number corresponding to both the system voltage and the cable insulation diameter in mm.
The complete kit comprises of 3 termination housings, installation instructions, special lubricant, wiper, adhesive tape and field control mastic.
| Voltage Um (kV) |
Conductor Sizes (sqmm) |
Diameter Over Core Insulation (mm) |
Number Of Sheds | L (mm) (max) |
Dia. D (mm) | Creepage Distance (mm) |
Nexans Ordering Part Number |
||
| min | max | min | max | ||||||
| 12kV | 25 | 95 | 12.7 | 21.0 | 3 | 210 | 90 | 369 | 3 x AFN 10-1 |
| 120 | 240 | 19.0 | 28.5 | 3 | 210 | 96 | 365 | 3 x AFN 10-2 | |
| 300 | 500 | 27.0 | 37.0 | 3 | 210 | 105 | 360 | 3 x AFN 10-3 | |
| 630 | 800 | 34.0 | 46.0 | 4 | 240 | 118 | 462 | 3 x AFN 20-4 | |
| 1000 | 39.0 | 50.0 | 7 | 405 | 127 | 755 | 3 x AFN 36-5 | ||
| 1200 | 46.0 | 58.0 | 7 | 405 | 127 | 755 | 3 x AFN 36-6 | ||
| 24kV | 35 | 70 | 18.0 | 23.5 | 4 | 240 | 100 | 480 | 3 x AFN 20-1 |
| 95 | 240 | 22.5 | 33.0 | 4 | 240 | 112 | 499 | 3 x AFN 20-2 | |
| 300 | 500 | 31.0 | 41.0 | 4 | 240 | 118 | 462 | 3 x AFN 20-3 | |
| 400 | 630 | 34.0 | 46.0 | 4 | 240 | 118 | 462 | 3 x AFN 20-4 | |
| 630 | 800 | 39.0 | 50.0 | 7 | 405 | 127 | 755 | 3 x AFN 36-5 | |
| 1000 | 1200 | 46.0 | 58.0 | 7 | 405 | 127 | 755 | 3 x AFN 36-6 | |
| 36kV | 50 | 70 | 23.5 | 29.0 | 6 | 300 | 115 | 695 | 3 x AFN 30-1 |
| 95 | 240 | 27.0 | 38.0 | 6 | 300 | 115 | 694 | 3 x AFN 30-2 | |
| 240 | 400 | 32.0 | 43.0 | 6 | 300 | 127 | 718 | 3 x AFN 30-3 | |
| 400 | 630 | 39.0 | 50.0 | 7 | 405 | 127 | 755 | 3 x AFN 36-5 | |
| 630 | 1000 | 46.0 | 58.0 | 7 | 405 | 127 | 755 | 3 x AFN 36-6 | |
| 42kV | 70 | 120 | 28.0 | 32.0 | 7 | 405 | 127 | 755 | 3 x AFN 36-3 |
| 150 | 300 | 31.5 | 41.0 | 7 | 405 | 127 | 755 | 3 x AFN 36-4 | |
| 400 | 630 | 39.0 | 50.0 | 7 | 405 | 127 | 755 | 3 x AFN 36-5 | |
| 630 | 1000 | 46.0 | 58.0 | 7 | 405 | 127 | 755 | 3 x AFN 36-6 | |
| For use in heavy polluted areas (cable terminations with an increased creepage length) | |||||||||
| 42kV | 70 | 120 | 28.0 | 32.0 | 11 | 535 | 127 | 1079 | 3 x AFNP 36-3 |
| 150 | 300 | 31.5 | 41.0 | 11 | 535 | 127 | 1079 | 3 x AFNP 36-4 | |
| 400 | 630 | 39.0 | 50.0 | 11 | 535 | 127 | 1079 | 3 x AFNP 36-5 | |
| 630 | 1000 | 46.0 | 58.0 | 11 | 535 | 127 | 1079 | 3 x AFNP 36-6 | |
Nexans
Thorne & Derrick distribute the complete range of medium/high voltage electrical equipment manufactured by Nexans – this includes Euromold bushings for use with oil fluid or gas insulated switchgear or transformers and associated screened separable connectors according to both IEC (Euromold) and IEEE (Elastimold) for the termination, connect+disconnect of MV-HV cables onto power distribution systems. To protect power systems against high voltage surges resulting from lightning or switching a complete range of surge arresters are available to be used with Euromold connectors in 11kV/12kV, 24kV and 33kV/36kV voltage classes.
