A225 Cable Glands LSF LSOH – Prysmian Bicon 423LSF-55
A225 Cable Gland LSF Kits
A225 LSF Gland
Prysmian Bicon 423LSF-55 (A225) A2 LSF cable glands with 25mm entry thread enable cable termination of unarmoured low smoke zero halogen cables – the A225 cable gland LSF kit provides mechanical cable retention up to 19.5mm cable diameters.
A225 LSF cable glands are LUL approved for safe use on London Underground including sub-surface (tunnels) and stations (LUL APR Product ID 1971).
A225 cable gland termination is available in a Nickel plated version Prysmian 423LSF-55V.
A225 Cable Gland Kit
London Underground (LUL) Rail Cables, Glands & Cable Cleats – Low Smoke Zero Halogen
LSF Low Smoke Zero Halogen
Prysmian Bicon Technical Specification
- Manufacturer: Prysmian
- Brand: Bicon
- Cable Gland Size: A225
- Quantity Per Kit: 2 Cable Glands
- Cable Gland Type: Brass
- Cable Type: SWA Steel Wire Armoured BS6724
- Specification: LSF Low Smoke & Fume | LSOH Low Smoke Zero Halogen
- Cable Diameter (B): 13.0mm Minimum
- Cable Diameter (B): 19.5mm Maximum
- Entry Thread (D) : M25 x 1.5
- Thread Length (E) : 10mm
- Protrusion Length (F): 25mm
- Hexagon A/F (G): 30.5mm
- Hexagon A/C (H): 34mm
- Order Code: A225 423LSF-55
- Industrial Application Also: Prysmian A225 Cable Gland KM409-55
A225 Cable Gland LSF Kit Contents: A1/A2 Gland, Brass Locknut and Low Smoke Zero Halogen Shroud (2 per kit up to and including 25mm size). Standard A225 cable glands are available in Brass and ATEX hazardous area certified type for flameproof and explosion proof cable termination – for cable terminations on armoured zero halogen power cables use BW brass glands.
A225 Cable Glands – terminate unarmoured low smoke zero halogen cables into conduit, trunking or switchgear and control gear.
➡ See also Prysmian Cable Cleats for clamping, supporting and cleating LV-HV cables.
Gland kit order code: pRYSMIAN A225 423LSF-55
Prysmian Bicon A2 LSF Cable Gland Kits – Dimensions Illustration
Cable Glands & Terminations
Cable glands available in brass, aluminium, nickel plated or stainless steel for the termination of LV wire armoured, wire braided and unarmoured cables, including low smoke zero halogen cables in industrial non-hazardous areas.
Complete range of MV-HV Cable Terminations for the connection of medium/high voltage power cables to electrical equipment available.
See more MV HV: Cold Shrink Terminations 3M | Heat Shrink Terminations
To provide cable support to cable glands and terminations at LV Low Voltage, MV Medium Voltage or HV High Voltage, T&D distribute a complete range of cable cleats.
