Indoor Cable Termination | Cold Shrink | Single Core | 11kV 33kV 42kV

Contact us for Euromold AIN | Large Stocks | Competitive Prices | Nexans Distributors


Cable Terminations

Euromold AIN are single core cold shrink slip-on cable terminations for use indoor and specified to terminate and connect medium/high voltage cables in the following voltage classes – Slip-on terminations are cold applied terminations require no “hot-working” for safe use in potentially explosive atmospheres and hazardous area locations.

  • 6/10 (12) kV
  • 6.35/11 (12) kV
  • 8.7/15 (17.5) kV
  • 12/20 (24) kV
  • 12.7/22 (24) kV
  • 18/30 (36) kV
  • 20.8/36 (42) kV

Euromold AIN have a kit of 3 terminations for use indoors in controlled environmental conditions and subject to light condensation. Suitable for connecting polymeric insulated (XLPE EPR) cable to MV-HV electrical equipment providing a quick and simple method of stress relieving on screened polymeric cables.

  • Voltage Classes – 11kV 33kV 42kV Maximum
  • Terminate & Connect Cables – Polymeric XLPE EPR
  • Single or 3 Core – Single Core
  • Cable Screen – Suit Both Copper Wire & Copper Tape Screen (Order Euromold MT Kit)
  • Location – Indoor Cable Termination
  • Conductor Cross Section Sizes – 25-1200sqmm
  • Applications – MV HV Switchgear, Transformers, Motors
  • Also Outdoor AFN Cold Shrink Terminations 11kV 33kV 42kV

➡ See complete range of Nexans Euromold Cable Terminations

Slip-on Terminations | 33kV medium voltage power cables terminated outdoors at a wind farm facility in harsh operating conditions subject to fluctuating cyclic loads, UV exposure and high rainfall levels – the hydrophobic, compact and cold-applied terminations provide reliable performance in both indoor (AIN switchgear) and outdoor (AFN pole-mounted) substation locations.

Slip-on Terminations | 33kV medium voltage power cables terminated outdoors at a wind farm facility in harsh operating conditions subject to fluctuating cyclic loads, UV exposure and high rainfall levels – the hydrophobic, compact and cold-applied terminations provide reliable performance in both indoor (AIN switchgear) and outdoor (AFN pole-mounted) substation locations.


Euromold AIN Slip on termination Specification

Euromold Termination
Slip On Cold Shrink
Voltage
Um
(kV)
Conductor Sizes (sqmm)
min max
Nexans Euromold AIN 10 12kV 25sqmm 1200sqmm
Nexans Euromold AIN 20 24kV 35sqmm 1200sqmm
Nexans Euromold AIN 30 36kV 50sqmm 1000sqmm
Nexans Euromold AIN 36 42kV 150sqmm 1000sqmm
Slip On Indoor Cable Terminations 11kV 33kV 42kV Euromold AIN - Design

Slip On Indoor Cable Terminations 11kV 33kV 42kV Euromold AIN – Design

Indoor slip-on cable termination kit list comprising:

    1. Cable lug (not included in the standard kit) – crimp lugs or shearbolt lugs are suitable
    2. High flexibility silicone rubber housing, allowing larger tolerances on cable insulation diameters, with integrated conductive rubber insert, providing stress relief
    3. Earthing lug (not included in the standard kit)


EUROMOLD AIN selection table

For Indoor MV HV Cable Terminations

Select the Euromold part number corresponding to both the system voltage and the cable insulation diameter in mm – the complete kit comprises of 3 termination housings, installation instructions, special lubricant, wiper, adhesive tape and field control mastic.

Voltage
Um
(kV)
Conductor
Sizes
(sqmm)
Diameter Over
Core Insulation
(mm)
Number Of Sheds L
(mm)
Dia. D (mm) Nexans AIN Ordering
Part Number
min max min max
12kV 25sqmm 95sqmm 12.7 21.0 2 150 37 3 x AIN 10-1
120sqmm 240sqmm 19.0 28.5 2 150 43 3 x AIN 10-2
300sqmm 500sqmm 27.0 37.0 2 150 60 3 x AIN 10-3
630sqmm 800sqmm 34.0 46.0 3 225 68 3 x AIN 36-4
1000sqmm 39.0 50.0 7 405 98 3 x AIN 36-5
1200sqmm 46.0 58.0 7 405 98 3 x AIN 36-6
24kV 35sqmm 70sqmm 18.0 23.5 3 225 47 3 x AIN 20-1
95sqmm 240sqmm 22.5 33.0 3 225 56 3 x AIN 20-2
300sqmm 500sqmm 31.0 41.0 3 225 68 3 x AIN 20-3
400sqmm 630sqmm 34.0 46.0 3 225 68 3 x AIN 20-4
630sqmm 800sqmm 39.0 50.0 7 405 98 3 x AIN 36-5
1000sqmm 1200sqmm 46.0 58.0 7 405 98 3 x AIN 36-6
36kV 50sqmm 70sqmm 23.5 29.0 6 300 74 3 x AIN 30-1
95sqmm 240sqmm 27.0 38.0 6 300 74 3 x AIN 30-2
240sqmm 400sqmm 32.0 43.0 6 300 81 3 x AIN 30-3
400sqmm 630sqmm 39.0 50.0 7 405 98 3 x AIN 36-5
630sqmm 1000sqmm 46.0 58.0 7 405 98 3 x AIN 36-6
42kV 150sqmm 300sqmm 31.5 41.0 7 405 98 3 x AIN 36-4
400sqmm 630sqmm 39.0 50.0 7 405 98 3 x AIN 36-5
630sqmm 1000sqmm 46.0 58.0 7 405 98 3 x AIN 36-6

Offshore Substation Terminations

This Video demonstrates the advanced material performance of silicone used in the manufacture of the Nexans AFN range of Cable Terminations up to 33kV – the cable terminations survived a serious blast fire in an onshore primary substation location. Despite the clear damage and fire aftermath, the Nexans AIN cable terminations remain intact and still functioning and are increasingly specified by design engineers for the termination of medium voltage cables in offshore unmanned installations.


Network Rail Supplier

Nexans Euromold

Network Rail Certificate of Acceptance | PADS PA05/06215

Euromold AFN 36 – 6 | 42kV Single Core Cable Termination

Euromold AFN36-6 42kV Single core cable termination for indoor 25kV air insulated switchgear. The Euromold AFN36-6 42kV single pole termination is approved for use on indoor cable terminations for Siemens ASG25, 25kV air insulated switchgear. Euromold AFN36-4-H 42kV terminations are no longer available and are superseded by the AFN36-6 type

Nexans 42kV Order Code AFN36-6 | Network Rail 054/214930

Euromold

Euromold | Connect | Joint | Terminate MV HV Cables – view our complete range of HV Joints & Terminations in heat shrink, cold shrink, push-on and plug-in versions for medium/high voltage cables.


Thorne & Derrick International are the Specialist Distributor for the Nexans Power Cable Accessory range of Screened Separable Connectors (Euromold), Cold-Applied (AIN AFN) & Heat Shrink Joints (JTS) & Cable Terminations (MONO) for Medium Voltage Power Systems up to 66kV; we hold extensive stocks and provide the most competitive commercial and technical levels of customer service in the UK.
