Draka Firetuf FTP120 Cable – Fire Resistant Armoured Power Cables (BS8519, Category 1,2 & 3)

Draka Firetuf FTP120 Cable - Fire Resistant Armoured Power Cables (BS8519, Category 1,2 & 3)

Draka Firetuf FTP120 Cable - Fire Resistant Armoured Power Cables (BS8519, Category 1,2 & 3)

Fire Resistant Cable

Draka Firetuf FTP120

Draka FTP120 is a Halogen Free, Low Smoke (0HLS) fire retardant armoured cable which provides superior fire resistance and circuit integrity. Designed and manufactured to BS8519, Category 1, 2 & 3, Draka FTP120 is manufactured in the UK.

FTP120 cable is third party approved by LPCB for 120 min classification in BS8491. This is the test for fire resistance that includes direct flame, direct impact and water jet at 850°C.

Draka FTP120 holds third party BASEC certification to BS7846, the construction requirements for fire rated armoured cables.

Draka Firetuf FTP120 Cable

features

  • Voltage rating (U0/U): 600/1000V
  • Operating Temperature: -25°C to +90°C (the cable should not be installed when either the ambient or cable temperature is below 0°C)
  • Minimum Bending Radius: 8 x overall diameter of cable
  • Manufacturing Standard: BS7846
  • Cable Conductors: Stranded (Class 2) plain annealed copper
  • Insulation: Mica-glass fire resistant tapes, covered by an extruded layer of XLPE
  • Binder: Polyester tape, glass tapes where performance requires
  • Bedding: Zero Halogen, Low Smoke (0HLS)
  • Armour: Galvanised Steel Wire Armour
  • Cable Sheath: Zero Halogen, Low Smoke (0HLS)
  • Circuit Integrity: BS 7846 F120, BS 8491 30, 60 and 120mins
  • Flame Propagation: BS EN 60332-1-2. BS EN 60332-3-24
  • Acid Gas Emission: BS EN 50267-2-1
  • Smoke Emission: BS EN 61034-2

Draka Fire Resistant Cables

Firetuf Fire Resistant Cables – powering critical safety systems including fire alarms, lighting, emergency lighting, PA systems and CCTV.

Draka Firetuf FTP120 Cable – Fire Resistant Armoured Power Cable Range

Nominal Area of Conductor (mm²) Armour Wire Diameter (mm) Diameter Under Armour (mm)(Approx.)  Approx. Overall Diameter (mm) Approx. Cable Weight (kg/km) Maximum Conductor Resistance Nominal Area of Armour (mm²) Maximum Armour Resistance at 20ºC (Ω/km)
DC at 20ºC (Ω/km) AC at 90ºC (Ω/km)
Two Core FTPP2H
4* 1.25 14.7 20.2 765 4.61 5.878 19 7.9
6* 1.25 14.7 20.2 760 3.08 3.927 22 7
10* 1.25 15.9 21.7 875 1.83 2.333 26 6
16* 1.25 17.2 22.9 1020 1.15 1.466 42 3.7
25* 1.25 20.2 26.1 1325 0.727 0.926 42 3.7
35* 1.6 22.5 29.3 1820 0.524 0.6685 60 2.6
50 1.6 23.5 29.5 2580 0.387 0.494 68 2.3
70 1.6 25.5 33.0 2045 0.268 0.3412 80 2
95 2.0 26.7 34.9 3465 0.193 0.2471 113 1.4
120 2.0 30.1 38.5 4150 0.153 0.1964 125 1.3
150 2.0 32.6 41.1 4845 0.124 0.1597 138 1.2
185 2.5 36.1 46.0 6235 0.0991 0.1284 191 0.82
240 2.5 40.7 50.8 7635 0.0754 0.0989 215 0.73
300 2.5 44.6 54.9 9155 0.0601 0.0801 235 0.67
400 2.5 49.8 60.4 11140 0.047 0.0641 265 0.59
Three Core FTPP3H
4* 1.25 14.7 20.2 785 4.61 5.878 20 7.5
6* 1.25 14.8 20.3 795 3.08 3.927 23 6.7
10* 1.25 17.0 22.7 1020 1.83 2.333 39 4
16* 1.25 18.3 24.2 1230 1.15 1.466 45 3.5
25* 1.6 21.8 28.5 1795 0.727 0.926 62 2.5
35* 1.6 24.0 31.0 2170 0.524 0.6685 68 2.3
50 1.6 25.1 32.1 2615 0.387 0.494 78 2
70 1.6 28.2 35.4 3360 0.268 0.3412 90 1.8
95 2.0 31.4 39.8 4605 0.193 0.2471 128 1.3
120 2.0 34.5 43.1 5505 0.153 0.1964 141 1.2
150 2.5 38.4 48.1 7010 0.124 0.1597 201 0.78
185 2.5 42.2 52.1 8295 0.0991 0.1284 220 0.71
240 2.5 46.9 57.1 10330 0.0754 0.0989 250 0.63
300 2.5 51.8 62.3 14425 0.0601 0.0801 269 0.58
400 2.5 57.6 68.4 15270 0.047 0.0641 304 0.52
Four Core FTPP4H
4* 1.25 15.0 20.5 795 4.61 5.878 22 6.8
6* 1.25 16.2 22.0 930 3.08 3.927 36 4.3
10* 1.25 18.7 24.4 1200 1.83 2.333 42 3.7
16* 1.25 20.2 26.1 1460 1.15 1.466 50 3.1
25* 1.6 24.0 30.8 2150 0.727 0.926 70 2.3
35* 1.6 26.6 33.6 2635 0.524 0.6685 78 2
50 1.6 29.0 36.2 3275 0.387 0.494 90 1.8
70 2.0 31.9 40.2 4555 0.268 0.3412 131 1.2
95 2.0 35.4 43.9 5770 0.193 0.2471 147 1.1
120 2.5 39.4 49.1 7380 0.153 0.1964 206 0.76
150 2.5 43.3 53.2 8720 0.124 0.1597 230 0.68
185 2.5 48.1 58.4 10535 0.0991 0.1284 255 0.61
240 2.5 53.6 64.0 13115 0.0754 0.0989 289 0.54
300 2.5 58.7 69.4 15805 0.0601 0.0801 319 0.49
400 3.15 65.6 78.1 20420 0.047 0.0641 452 0.35

*Circular conductors, all others are shaped conductors

Prysmian Draka Cables

âž¡ Draka is a Prysmian brand – see also Low Smoke Zero Halogen and Offshore & Marine Cables.
