A Guide To HV Efficiency: Optimising Efficiency With Remote Monitoring (Part 3 of 3)

Published 12 Sep 2019

A Guide To HV Efficiency Optimising Efficiency With Remote Monitoring

A Guide To HV Efficiency Optimising Efficiency With Remote Monitoring


HV Efficiency: Optimising Efficiency With Remote Monitoring (Part 3 of 3)

Uploaded by Chris Dodds – Thorne & Derrick Sales and Marketing Manager


Our first two instalments in this HV efficiency blog series explored the benefits of upgrading from a traditional CRGO transformer to a super-low-loss amorphous core transformer. We also examined how these technologies can help businesses improve energy efficiency.

In Part 2, we explained the difference between tapping down HV transformers and using voltage management technologies, such as voltage optimisation.

Now, in this final instalment, we explore the benefits of installing a smart distribution transformer with remote monitoring capabilities. This technology helps businesses monitor transformer performance and energy use when their voltage profile does not require voltage management.

Distribution Transformer With Remote Capabilities

Distribution Transformer With Remote Capabilities


The Smart Way to Transform Energy

Technology continues to advance, and connectivity now plays an increasingly important role in electrical equipment. This shift towards connected systems forms part of the wider move towards Industry 4.0.

However, distribution transformers have been slower than other electrical equipment to adopt internet connectivity and smart monitoring technologies. These developments can give businesses greater visibility of asset performance, condition and diagnostics.

Distribution transformers play a vital role in the UK’s HV infrastructure. In most installations, they remain energised around the clock, even when they do not carry a load. This helps maintain an acceptable electrical supply for the building.

As a result, an unexpected transformer fault or breakdown can seriously disrupt business operations. These problems can also prove difficult to predict, particularly between scheduled inspections.


Manage Your Energy Effectively

Until recently, businesses had limited options for upgrading their existing distribution transformers with connectivity features. Now, smart transformer technology allows companies to connect their equipment to energy-saving systems and smart building controls.

With these connections in place, businesses gain greater visibility of their energy use and transformer performance. They can also use this information to make more informed decisions about their electrical infrastructure.

Traditional distribution transformers often operate as standalone equipment after installation. Although routine maintenance and inspections remain important, annual manual inspections alone cannot provide continuous information about transformer condition or site energy use.

Smart distribution transformers offer a more connected approach. For example, Powerstar SO-LO provides internet connectivity and remote monitoring capabilities.

Through remote monitoring, users can access clear information about transformer condition and performance. The system presents key statistics in an easy-to-understand format, making it simpler to monitor electrical assets.

Smart Transformers LV MV HV 415V - 11kV 33kV Distribution Transformers Powerstar SO-LO

Smart Transformers LV MV HV 415V – 11kV 33kV Distribution Transformers Powerstar SO-LO

What Can Remote Monitoring Measure?

Depending on the system, remote monitoring can provide access to a range of useful information, including:

  • Grid information
  • Transformer condition and performance
  • Energy efficiency reports
  • Oil analysis
  • Voltage and current (amps)
  • Phase-to-phase measurements
  • Real power and power factor
  • Core temperature
  • Harmonic distortion
  • System kVA and kWh
  • GPS location for larger facilities

By reviewing this information, businesses can identify potential improvements and investigate further energy savings. In addition, these insights can help companies optimise transformer performance and make better-informed investment decisions.

Identify Potential Problems Earlier

Like any electrical equipment, smart transformers can develop faults that may lead to an unplanned shutdown. However, remote monitoring can help identify potential problems at an earlier stage.

When the system detects an issue, it can send an alert or warning to the relevant people. Maintenance teams can then investigate the problem and take action before it affects the building’s electricity supply.

Furthermore, authorised users can access the monitoring platform from different locations through a secure internet connection. This makes it easier to review transformer data without needing to visit the equipment in person.

Regularly reviewing this information also helps businesses take a more proactive approach to transformer maintenance. By identifying potential issues earlier, companies can help reduce equipment downtime and the costs associated with failures and repairs.


Powerstar and Thorne & Derrick Partnership

Powerstar, a UK manufacturer of smart energy solutions, announced a new partnership with Thorne & Derrick International to strengthen its smart transformer offering for energy-conscious businesses.

The partnership supports companies looking to improve their existing medium- and high-voltage (MV/HV) infrastructure. In turn, these solutions aim to maximise efficiency while reducing electricity consumption and costs.

Powerstar’s smart transformer technology also provides real-time asset monitoring. Consequently, users can gain greater visibility of equipment performance and operation.

Powerstar LV MV HV Transformers

Powerstar LV MV HV Transformers
