A Guide To HV Efficiency: The Core Of The Problem (Part 1 of 3)
Published 12 Sep 2019

A Guide To HV Efficiency The Core Of The Problem
HV Efficiency in the Energy Industry: The Core of the Problem (Part 1 of 3)
Uploaded by Chris Dodds – Thorne & Derrick Sales and Marketing Manager
The energy industry continues to evolve, with new technologies and developments emerging regularly. However, understanding how these changes affect your electrical infrastructure can be challenging.
Powerstar helps simplify these developments by keeping clients informed about new technologies. As a result, businesses can make better-informed decisions about their energy infrastructure, including their 11kV transformers.
Throughout this three-part blog series, we explore how businesses can improve the efficiency of their HV infrastructure. In particular, we examine three important areas:
- The benefits of installing a super-low-loss amorphous core transformer instead of a traditional CRGO transformer.
- The difference between stepping down transformer voltage and using purpose-built voltage management technologies, such as voltage optimisation.
- The advantages of installing a smart distribution transformer with integrated remote monitoring capabilities.
Following its acquisition of Bromsgrove Winding Services (BWS) Ltd, Powerstar expanded its smart energy solution capabilities to include distribution transformers.
Consequently, Powerstar can now advise clients on improving HV infrastructure efficiency and identifying opportunities to enhance their electrical systems.

Greater Efficiency Starts at the Core
Many businesses look to upgrade their HV infrastructure to improve efficiency and reduce electricity consumption. This demand has encouraged manufacturers to develop transformer core materials that deliver lower energy losses than traditional alternatives.
One example is amorphous alloy core technology, which has demonstrated positive results across numerous applications through testing and performance studies.
Unlike conventional CRGO steel, amorphous alloy has a less ordered atomic structure. This allows the material to magnetise and demagnetise more easily. As a result, transformers can experience lower core losses and reduce wasted energy.
In addition, manufacturers can design distribution transformers around the specific requirements of each site. Bespoke transformers, designed and delivered from concept to completion, can therefore help businesses improve site resilience and overall HV efficiency.
Why Upgrade Your HV Transformer?
Distribution transformers can have a life expectancy of up to 40 years. However, many older units use materials and technology that do not offer the same efficiency as modern transformer designs.
At the same time, environmental considerations have become increasingly important for businesses. When planning a transformer upgrade, companies should therefore consider equipment that can improve energy efficiency and help reduce carbon emissions.
Compared with older transformer designs, modern amorphous core transformers can deliver significant improvements in efficiency. For example, new amorphous core transformers can achieve up to 75% lower core losses than traditional CRGO transformers.

Super Low Loss Transformers Up To 11kV By Powerstar SO-LO
Furthermore, bespoke solutions such as the Powerstar SO-LO amorphous core transformer meet and exceed the 2021 EU Ecodesign Directive standards set by the European Commission.
Older transformers may not meet these standards. Therefore, despite their long operational life, some existing units may fall behind modern efficiency requirements.
By replacing a traditional transformer with a more efficient amorphous core model, businesses that manage their own HV infrastructure can reduce energy consumption and associated electricity costs.

LV MV HV Transformers
Further Reading
Continue exploring our three-part HV efficiency series:
- A Guide To HV Efficiency: Distribution Transformers & Voltage Management (Part 2 of 3)
- A Guide To HV Efficiency: Optimising Efficiency With Remote Monitoring (Part 3 of 3)
