11kV 12kV Cable Termination Kits Single Core 300-500sqmm SPS 1TIS-12X-D
11kV cable termination kits using heat shrink technology are suitable for terminating medium/high voltage (MV-HV) single core polymeric cables (XLPE EPR)  – this includes cables with copper wire/tape screen and armoured (wire armoured/braided) or unarmoured cable for indoor termination of 11kV cables, outdoor version also available.
SPS 1TIS-12X-DÂ cable termination kit suits 11kV cables with 300sqmm, 400sqmm, 500sqmm single core conductors.
11kV Cable Termination
HV High Voltage – indoor
- Cable Termination Type – Heat Shrink
- Cable Voltage – 11kV
- Termination Location –Â Indoor
- Number of Cores – Single Core
- Conductors – 300sqmm, 400sqmm, 500sqmm
- Cable Type – XLPE EPR (Polymeric)
- Heat Shrink Standard Tail Length – 350mm
- Termination Kit Order Code –Â SPS 1TIS-12X-D
- Suit MV HV Power Cables – BS6622, BS7835, BS7870, BS6883, BS7917 & IEC60502-2
11KV Single Core Power Cable
âž¡Â High Voltage Cable Termination 11kV Kit List
➡ 11kV Cable Terminations | 3 Core Indoor 11kV XLPE | 3 Core Outdoor 11kV XLPE
11kV Cable Installation Equipment | Cleats | Lugs | Glands | Joints | Cable Tooling – leading manufacturers including Furse, CMP, Pfisterer, Prysmian, Alroc & Nexans Euromold
11kV Terminations Single Core XLPE
indoor Cable Termination Kits
The following enables the termination kit selection for 11kV single core indoor cables:
|  11kV Cable Termination Indoor | Heat Shrink Cable Termination Kit Range | 11kV Cable Termination Outdoor |
| 1TIS-12X-A | 16-25sqmm | 1TES-12X-A |
| 1TIS-12X-B | 35-95sqmm | 1TES-12X-B |
| 1TIS-12X-C | 120-240sqmm | 1TES-12X-C |
| 1TIS-12X-D | 300-500sqmm | 1TES-12X-D |
| 1TIS-12X-E | 630-800sqmm | 1TES-12X-E |
Cable terminations using heat shrink technology for MV-HV (6.6kV 11kV 33kV) cable connection to switchgear, transformers, overhead line and pole-mounted – see also Heat Shrink HV Cable Joints
