MV Jointing & Cable Stripping Using Ripley US02-7000 Tool
Published 30 Aug 2023
Here the MV Jointer, Steffan Evans from HVSM, is shown expertly stripping bonded semi-conductor screen from medium voltage power cables (20/22kV) prior to terminating the cable into Siemens NXAIR type Vacuum Circuit Breaker – the Ripley US02-7000 comfortably caters for the precision stripping of the bonded screen from the 400sqmm cable for preparation of the Raychem (Tyco) heat shrink termination to be installed.
The US02 Tool manufactured by Ripley Tools features a revolving ergonomic handle and accessible adjustment knobs for comfort and ease-of-use, reducing effort and potential strain for cable jointers performing repetitive shaving functions in the field.
“Investing in innovation and introducing cable jointing tools to HVSM improves safety and reliability for our clients. The Ripley US02 is very Jointer-friendly with a spectacular finish to the XLPE insulation – the automatic cut-off and incremental blade adjustments ensure a professional perfection of cable preparation at medium voltages,” comments Steffan.
Stripping in the Switch | the US02 Tool is compact but robust allowing confined space working in Medium Voltage Electrical Equipment.
The US02 Tool provides an exceptionally smooth finish and does not require lubricating grease as the integral wheels provide a sustained motion during the cable preparation process – the US02 has four settings on it that adjust the pitch as it winds down the cable and a stop that enables the jointer to provide a square cut to finish off. The settings are 0.5mm, 1mm, 1.5mm and 2mm.
No Grease & No Clamps | Precision Accuracy & Effortless Repeatability for MV Jointing
MV Jointing Tools
HVSM are one of Ireland’s most long-standing High Voltage Engineering companies, which has been operating since 1991. Headquartered in Ireland but present and operating globally, they
provide best in class specialist service for High Voltage Power Industries such as Commercial, Utilities, Manufacturing, Life Science, Data Centres as well as the Renewable Energy Sector.
