Bi-Metallic Cable Lugs Connectors LV MV HV 11kV-33kV - Cembre CAA

Bi-Metallic Cable Lugs Connectors LV MV HV 11kV-33kV – Cembre CAA

Cembre CAA

Cembre CAA cable lug connectors are manufactured from high quality aluminium.

The lug barrel of Cembre CAA connectors is friction welded to the palm therefore achieving the best possible transition between the copper palm of the cable lug and aluminium barrel – single hole cable lugs are used to terminate and connect LV-HV cables with stranded circular aluminium conductor (Class 2) onto copper busbar in switchgear, control panels and cable boxes.

Aluminium cables with solid sectoral shaped conductor (Class 1) can be terminated by pre-rounding of the conductor before positioning over the cable prior to crimping using hydraulic and battery operated crimping tools.

Oxidation within the cable lug is prevented by protecting the internal surface with a specific grease with a very high dropping point.

The bi-metallic cable lugs connectors are suitable for connecting LV, MV and HV stranded aluminium conductor cables including 11kV-33kV medium voltage with conductor cross section areas 10sqmm-630sqmm. Used to terminate and crimp stranded aluminium cables with conductors according to BS EN 60228:2005.

Cembre CAA bi-metallic cABLE LUGS

Part Cable Lug Barrel 1 Palm Fixing Cu ETP
Designation Aluminium AL 99.5 Copper Cu ETP CW 0041A
Standard Of Reference UNI EN 573-3 : 2009 UNI EN 13600 : 2003
Electrical Resistance AT 20 °C (pS2•cm)  2,874 1,724 ÷ 1,70
Breaking Resistance (N/m m2) 85 ÷ 129 225
Stretching A5 % 10 ÷ 23 35



Bi-Metallic Cable Lugs Connectors LV MV HV 11kV-33kV - Cembre CAA

Cable Lugs Connectors LV MV HV 11kV-33kV – Cembre CAA

Bi-Metallic Cable Lugs

Cembre CAA Product Specification

Cembre Cable Lug Part Ref Aluminium Conductor Cross Section Area of Cable (Class 2) Die Set  Ø Stud Hole mm Dimensions mm Voltages Quantity
Box/Bag
Cembre  Øi B L D LV MV HV
CAA 10-M 12 10sqmm MK16-C 12 4,3 24,0 87,0 13,0 1,000V 11kV 33kV 90/3
CAA 16-M 12 16sqmm MK16-C 12 5,5 24,0 87,0 13,0 1,000V 11kV 33kV 90/3
CAA 25-M 12 25sqmm MK16-C 12 6,5 24,0 87,0 13,0 1,000V 11kV 33kV 90/3
CAA 35-M 12 35sqmm MK20-C 12 8,0 24,0 87,0 13,0 1,000V 11kV 33kV 90/3
CAA 35-20-M 12 MK20-C 12 8,0 24,0 87,0 13,0 1,000V 11kV 33kV 60/3
CAA 50-M 12 50sqmm MK20-C 12 9,0 24,0 87,0 13,0 1,000V 11kV 33kV 60/3
CAA 70-M 12 70sqmm MK20-C 12 11,0 24,0 87,0 13,0 1,000V 11kV 33kV 60/3
CAA 95-M 12 95sqmm MK20-C 12 12,5 24,0 87,0 13,0 1,000V 11kV 33kV 60/3
CAA 120-M 12 120sqmm MK25-C 12 13,7 31,0 111,0 13,0 1,000V 11kV 33kV 30/3
CAA 150-M 12 150sqmm MK25-C 12 15,5 31,0 111,0 13,0 1,000V 11kV 33kV 30/3
CAA185-M 12 185sqmm MK32L-C 12 17,0 35,0 116,0 13,0 1,000V 11kV 33kV 24/3
CAA 240-M 12 240sqmm MK32L-C 12 19,5 35,0 116,0 13,0 1,000V 11kV 33kV 18/3
CAA 300-34 M 12 300sqmm MK34L-C 12 22,5 35,0 120,0 13,0 1,000V 11kV 33kV 15/3
CAA 300-34 M 16 MK34L-C 16 22,5 35,0 120,0 17,0 1,000V 11kV 33kV 15/3
CAA 300-M 16 MK38-3D 16 23,3 35,0 152,5 16,5 1,000V 11kV 33kV 12/3
CAA 400-M 16 400sqmm MK38-3D 16 26,0 35,0 152,5 16,5 1,000V 11kV 33kV 12/3
CAA 500-M 16 TNBD 500sqmm MK38-3D 16 29,1 35,0 152,5 16,5 1,000V 11kV 33kV 12/3
CAA 630-4 M 8 630sqmm MK46-3D 8 32,5 60,0 192,0 4 x 9,0* 1,000V 11kV 33kV 9/3

*n° 4 holes with 30 mm as distance between axes

➡ See also aluminium cable lugs and copper cable lugs for 11kV-33kV medium and high voltage cable connections and terminations.

Cembre CAA - Dimensions

Cembre CAA – Dimensions

How To Install Crimp Connectors Onto Aluminium Conductors Using The Deep Step Indenting Method
  1. Unsheath and strip the aluminium conductor then shape the conductor to a round and compact configuration using the pre-rounding die set appropriate to this type of cable conductor size, shape and stranding, this includes LV, MV and HV cables
  2. Insert aluminium conductor into the Cembre cable lugs or connectors
  3. Select the relevant Cembre compression die set (MV) and associated indentor (PS130) to the connector to be crimped and then locate them carefully into the hydraulic crimping tool or presshead
  4. Indent the electrical connector in the sequence show below (FIG 2). Note, for a through splice connector indent the outer positions first, followed by the inner positions. For a cable lug indent the position near the cable conductor first, followed by the position near the cable lug palm.
  5. After indenting the crimp connector, fill the indents with the compound provided with the Cembre connectors, lugs or splices

Note: The sequence must be followed in order to obtain the correct conductor fill coefficient essential for producing a stable electrical connection to aluminium conductor on medium/high voltage cables.

Crimping Cables Using Cembre Lugs - Deep Step Indenting

Crimping Cables Using Cembre Lugs & Connectors – Deep Step Indenting

➡ T&D are Main Distributors for Cembre stocking a complete range of cable cutting and crimping tools.Cembre - Cable Crimpers Cutters Lugs Splices

Contact T&D to discuss crimping cables at MV-HV, including 11kV-33kV, to ensure correct Cembre tool, lug/splice and die set selection – visit battery crimping tools for repetitive crimping of cables without strain injury or worker fatigue.

Full range of battery cable cutting tools also available.
