BS1 Bar To Steel Surface

BS1

BS1

  • Product Category: Exothermic Welding
  • Order Code: BS1
  • Application: Bar to Steel Surface Exothermic Welding Connector

Used to weld flat copper tape conductors according to the sizes in the selection table below.

➡ Complete range of Earthing & Lightning Protection products manufactured from copper including earth rods, bars, tapes, clamps and ancillary items.

A Conductor mm x mm Weld Powder Exothermic Welding Mould Handle Clamp
20 x 3 WEP 065 BS1-C-203 HCC 001
25 x 3 WEP 090 BS1-C-253
25 x 4 BS1-C-254
25 x 6 WEP 150 BS1-C-256
30 x 2 WEP 090 BS1-C-302
30 x 3 BS1-C-303
30 x 4 WEP 115 BS1-C-304
30 x 5 WEP 150 BS1-C-305
31 x 3 WEP 090 BS1-C-313
31 x 6 WEP 200 BS1-C-316
38 x 3 WEP 150 BS1-C-383
38 x 5 WEP 200 BS1-C-385
38 x 6 WEP 250 BS1-C-386
40 x 3 WEP 150 BS1-C-403
40 x 4 WEP 200 BS1-C-404
40 x 5 BS1-C-405
40 x 6 WEP 250 BS1-C-406
50 x 3 WEP 200 BS1-C-503
50 x 4 WEP 250 BS1-C-504
50 x 5 BS1-C-505
50 x 6 2 x WEP 150 BS1-D-506 HCD 001
