CR2 Cable To Earth Rod
CR2
- Product Category: Exothermic Welding
- Order Code: CR2
- Application: Cable to Earth Rod Exothermic Welding Connector
Used to weld copper conductors according to the sizes in the selection table below.
➡ Complete range of Earthing & Lightning Protection products manufactured from copper including earth rods, bars, tapes, clamps and ancillary items.
A Earth Rod mm | B Earth Rod inches | C Conductor sqmm | Weld Powder | Exothermic Welding Mould | Handle Clamp |
12.7 | 1/2″ | 16 | WEP 090 | CR2-C-12716 | HCC 001 |
25 | CR2-C-12725 | ||||
35 | CR2-C-12735 | ||||
8mm ∅ | WEP 065 | CR2-C-1278SC | |||
50 | WEP 090 | CR2-C-12750 | |||
70 | CR2-C-12770 | ||||
95 | WEP 115 | CR2-C-12795 | |||
120 | WEP 150 | CR2-C-127120 | |||
150 | CR2-C-127150 | ||||
185 | WEP 200 | CR2-C-127185 | |||
240 | CR2-C-127240 | ||||
300 | WEP 250 | CR2-C-127300 | |||
14.2 | 5/8″ | 16 | WEP 065 | CR2-C-14216 | HCC 001 |
25 | WEP 090 | CR2-C-14225 | |||
35 | CR2-C-14235 | ||||
8mm ∅ | CR2-C-1428SC | ||||
50 | CR2-C-14250 | ||||
70 | WEP 115 | CR2-C-14270 | |||
95 | CR2-C-14295 | ||||
120 | WEP 150 | CR2-C-142120 | |||
150 | WEP 200 | CR2-C-142150 | |||
185 | CR2-C-142185 | ||||
240 | WEP 250 | CR2-C-142240 | |||
300 | 2 x WEP 150 | CR2-D-142300 | HCD 001 | ||
17.2 | 3/4″ | 16 | WEP 090 | CR2-C-17216 | HCC 001 |
25 | CR2-C-17225 | ||||
35 | CR2-C-17235 | ||||
8mm ∅ | WEP 115 | CR2-C-1728SC | |||
50 | CR2-C-17250 | ||||
70 | CR2-C-17270 | ||||
95 | CR2-C-17295 | ||||
120 | WEP 150 | CR2-C-172120 | |||
150 | WEP 200 | CR2-C-172150 | |||
185 | CR2-C-172185 | ||||
240 | WEP 250 | CR2-C-172240 | |||
300 | 2 x WEP 150 | CR2-D-172300 | HCD 001 |
