CR1 Cable To Earth Rod

CR1

CR1

  • Product Category: Exothermic Welding
  • Order Code: CR1
  • Application: Cable to Earth Rod Exothermic Welding Connector

Used to weld copper conductors according to the sizes in the selection table below.

➡ Complete range of Earthing & Lightning Protection products manufactured from copper including earth rods, bars, tapes, clamps and ancillary items.

A Earth Rod mm B Earth Rod inches C Conductor sqmm Weld Powder Exothermic Welding Mould Handle Clamp
12.7 1/2″ 16 WEP 065 CR1-C-12716 HCC 001
25 CR1-C-12725
35 CR1-C-12735
8mm ∅ CR1-C-1278SC
50 CR1-C-12750
70 WEP 090 CR1-C-12770
95 CR1-C-12795
120 CR1-C-127120
150 WEP 115 CR1-C-127150
185 CR1-C-127185
240 WEP 150 CR1-C-127240
300 CR1-C-127300
14.2 5/8″ 16 WEP 065 CR1-C-14216 HCC 001
25 CR1-C-14225
35 CR1-C-14235
8mm ∅ WEP 090 CR1-C-1428SC
50 CR1-C-14250
70 CR1-C-14270
95 CR1-C-14295
120 CR1-C-142120
150 WEP 115 CR1-C-142150
185 CR1-C-142185
240 WEP 150 CR1-C-142240
300 WEP 200 CR1-C-142300
17.2 3/4″ 16 WEP 065 CR1-C-17216 HCC 001
25 CR1-C-17225
35 CR1-C-17235
8mm ∅ WEP 090 CR1-C-1728SC
50 CR1-C-17250
70 CR1-C-17270
95 CR1-C-17295
120 CR1-C-172120
150 WEP 115 CR1-C-172150
185 CR1-C-172185
240 WEP 150 CR1-C-172240
300 WEP 200 CR1-C-172300
