CB5 Cable To Bar

CB5

CB5

  • Product Category: Exothermic Welding
  • Order Code: CB5
  • Application: Cable to Bar Exothermic Welding Connector

Used to weld copper conductors according to the sizes in the selection table below.

➡ Complete range of Earthing & Lightning Protection products manufactured from copper including earth rods, bars, tapes, clamps and ancillary items.

A Conductor sqmm B Conductor mm x mm Weld Powder Exothermic Welding Mould Handle Clamp
16 20 x 3 WEP 045 CB5-C-16203 HCC 001
25 x 3 WEP 065 CB5-C-16253
25 20 x 3 WEP 045 CB5-C-25203
25 x 3 WEP 065 CB5-C-25253
35 20 x 3 WEP 045 CB5-C-35203
25 x 3 WEP 065 CB5-C-35253
8mm ∅ 20 x 3 CB5-C-8SC203
25 x 3 CB5-C-8SC253
50 20 x 3 CB5-C-50203
25 x 3 CB5-C-50253
70 25 x 3 WEP 090 CB5-C-70253
25 x 4 WEP 115 CB5-C-70254
25 x 6 CB5-C-70256
95 25 x 3 CB5-C-95253
25 x 4 WEP 150 CB5-C-95254
25 x 6 CB5-C-95256
120 25 x 3 CB5-C-120253
25 x 4 CB5-C-120254
25 x 6 CB5-C-120256
30 x 5 WEP 200 CB5-C-120305
150 25 x 6 CB5-C-150256
30 x 5 CB5-C-150305
40 x 5 WEP 250 CB5-C-150405
50 x 3 WEP 200 CB5-C-150503
50 x 4 WEP 250 CB5-C-150504
50 x 6 2 x WEP 150 CB5-D-150506 HCD 001
50 x 8 2 x WEP 200 CB5-D-150508
185 30 x 5 WEP 250 CB5-C-185305 HCC 001
31 x 6 CB5-C-185316
38 x 6 CB5-C-185386
40 x 5 CB5-C-185405
50 x 4 CB5-D-185504 HCD 001
50 x 5 2 x WEP 150 CB5-D-185505
50 x 6 CB5-D-185506
50 x 8 2 x WEP 200 CB5-D-185508
240 50 x 3 2 x WEP 150 CB5-D-240503
50 x 4 CB5-D-240504
50 x 5 CB5-D-240505
50 x 6 2 x WEP 200 CB5-D-240506
300 50 x 6 2 x WEP 250 CB5-D-300506
50 x 8 CB5-D-300508
