Pfisterer 332599010 Connectors

332599010

Pfisterer 332599010, from the Sicon range of connectors, are Network Rail Approved Connectors with PADS approval for jointing, terminating and connecting trackside power cables, signal and telecoms up to 33kV.

This cable lug can accept a range of solid or stranded, aluminium or copper conductors and is designed for use with all types of Cold Shrink and heat shrink cable joints.

Order Reference – Pfisterer Sicon 332599010
Conductor cross section Al solid circular – 25-150sqmm
Conductor cross section Al stranded circular – 25-150sqmm
Conductor cross section Al stranded circular compressed 25-150sqmm
Conductor cross section Al solid sector-shaped 35-120sqmm
Conductor cross section Al stranded sector-shaped 35-120sqmm
Conductor cross section Cu solid circular 25-150sqmm
Conductor cross section Cu stranded circular 25-150sqmm
Conductor cross section Cu stranded circular compressed 25-150sqmm
Conductor cross section Cu stranded sector-shaped 35-120sqmm
Number of screws – 4
Mounting hole – 13 Ø (mm)
Width across flats – SW6
PADS Number Network Rail Approved Cable Lug Connectors – 054/039337
Also from Pfisterer | CONNEX Connectors | Bushings | Surge Arresters

SICON bolted cable lug 25-150sqmm

PFISTERER SICON SELECTION TABLE

Pfisterer Sicon Order Reference	332599010
Network Rail PADS Number	054/039337
Conductor cross section Al solid circular	25 – 150sqmm
Conductor cross section Al stranded circular	25 – 150sqmm
Conductor cross section Al stranded circular compressed	25 – 150sqmm
Conductor cross section Al solid sector-shaped	35 – 120sqmm
Conductor cross section Al stranded sector-shaped	35 – 120sqmm
Conductor cross section Cu solid circular	25 – 150sqmm
Conductor cross section Cu stranded circular	25 – 150sqmm
Conductor cross section Cu stranded circular compressed	25 – 150sqmm
Conductor cross section Cu stranded sector-shaped	35 – 120sqmm
Number of screws	2
Mounting hole	13 Ø (mm)
Width across flats	SW 5
