Welcome to our initial industry bulletin – VOLTS.
So what is VOLTS?
VOLTS is our first monthly round-up of industry news, projects, videos, technical tips, training information, promotions, webinars and career opportunities from Thorne & Derrick. Take a moment to Follow Us on LinkedIn to receive future VOLTS.
pROJECTS & NEWS
Port Of Felixstowe
Credit: https://www.portoffelixstowe.co.uk/
This month, we have been working with our client Hutchison Port Holdings and their High Voltage Engineering Team to supply a specification solution to repair and joint flexible reeling type EPR cables – the 11kV medium voltage power cables operating the quay and rail mounted gantry cranes at Port of Felixstowe required a permanent, compact, smooth profile and flexible cable sheath repair product.
Thorne & Derrick’s proposed solution using the M Series of Flexible Cable Repair Products manufactured by 3M Electrical, combines permanence with flexibility and reliability when installed by approved jointers.
The cable damage details:
- 1m of outer sheath tape delaminating where the cable was previously jointed under warranty by the manufacturer. The cable was removed and on a drum ready for repair.
- 2.72m of outer sheath damage. The cable was still working on the cranes with a temporary repair in place. The cables needed to be repaired in situ with a shelter and work area erected around the damage to allow for dry and convenient cable jointing.
This specification has been adopted as the engineering standard for future repairs to site damaged cables at Hutchison Ports operating facilities.
➡ Listen to Rachel Salisbury (Application Engineer 3M UK plc) explain the benefits;
Thorne & Derrick have been Distributors for 3M Electrical since 1985 and can provide customised repair solutions using Scotchcast resins, Cold Shrink or high performance tape repairs across all industry sectors. More Reading:
- Cable Repair Tape & Heat Shrink Sleeve From 3M Electrical For VFD Cables
- 3M Wraparound Heat Shrink Cable Repair Kits Used For LV HV Mining Cable Sheaths
- 3M Cold Shrink Tubes For Electric Submersible Pump (ESP) Cable Repair
- Submersible Cable Repair | Repair Damaged Offshore Firepump Cables
- Using “Heat Shrink Wraparounds” To Repair High Voltage Transmission Cables In Underground Cable Vault
Best For The Environment – Investing In A Low Carbon Future
The Port of Felixstowe is Britain’s biggest and busiest container port, and one of the largest in Europe – dealing with 48% of Britain’s containerised trade. Thorne & Derrick are also delighted to be working with a site that is committed to reducing their carbon footprint. While the Port of Felixstowe itself actually contributes less than 1% of the total carbon embedded in goods through the supply chain, they are committed to making significant progress in reducing this, as well as the impact of the overall supply chain.
HVDC | France to Italy Link
A New Power Highway Through The Alps To Build Europe’s Energy Grid
GE Grid are currently working on a high-voltage, direct current (HVDC) electric power transmission system to support the interconnection of the European Grid. Transitioning towards better integration of renewable power and reducing carbon footprint, transmission operators RTE (France) and TERNA (Italy) have decided to build the world’s longest (HVDC) cable interconnection. This link – at 190 km – will join the French and Italian electricity networks under the Alps.
Credit: https://www.gegridsolutions.com/
As Approved Vendors to GE Grid, Thorne & Derrick were invited to submit technical and commercial recommendations for portable and temporary earthing equipment to converter stations to ensure workers’ safety against hazards such as electric shocks while working within medium and high voltage substations.
Previously, Thorne & Derrick delivered similar bespoke portable earthing solutions to GE Grid for the safe electrical isolation works to the onshore and offshore substations at DolWin3 – this was the third offshore grid connection in the so-called DolWin cluster. The offshore grid connection connects the wind farms Merkur Offshore and Borkum Riffgrund 2 in the south-western part of the German North Sea with the onshore transmission grid.
Thorne & Derrick are a leading Specialist Distributor of Electrical Safety Equipment up to 400kV to both UK and international projects.
Talk to us about LV HV Voltage Detection | Cable Spiking | Portable Earthing Leads & Short Circuit Solutions (UK DNO, Network Rail PADs & National Grid Type Approved) | Cable Preparation Tools | Electrical Safety Products.
Pre-Wired Power
HMP Wandsworth Prison Square Substation
Working with Vinci Facilities, Thorne & Derrick have secured technical qualification and commercial acceptance of our specification for the design and supply of a pre-wired feeder pillar for an 800kVA mains transformer connection on the UKPN network. The customised feeder pillar from the Fortress range will be manufactured by Lucy Zodion with IP65 rating, enclosed busbar chamber and internal electrical wiring to client specification.
Working with Lucy Zodion and their highly skilled and experienced in-house electrical design and engineering teams we can provide high-quality power distribution solutions – contact us to discuss your requirements.
Other January projects included: South Thamesmead Development, Temple Green Park & Ride, Galileo 6 plus several housing developments and electric-vehicle (EV) charging stations throughout the UK.
The Lucy Zodion range of feeder pillar enclosures and cabinets are robust, durable and secure providing weatherproof and padlockable vandal resistant protection for external power distribution applications.
T&D supply Feeder Pillars from stocks overnight at the most competitive prices.
Powering the Future
This month, Thorne & Derrick achieved Approved Vendor status with Ventient Energy, the largest independent generator of onshore wind energy in Europe – we are now working with their Asset Managers & SAP’s to improve electrical site safety and outage response capabilities throughout their asset portfolio.
Let’s Meet
Throughout January, Thorne & Derrick continued to welcome their supply chain to our offices and we also conducted online meetings to ensure staff are up-to-date with product developments, discuss sales-marketing campaigns and strategy plan for 2022 with our team.
Pictured left-to-right Sarah Henderson, Carl Cox, Jonathan Hewitt, Phil Day, Jeff Jhanke, Natalie Lundie and Chris Dodds
Thorne & Derrick welcomed Phil Day from Slingco Limited, the world-leading manufacturer of cable pulling and support socks, swivels, cable protectors, wire rope assemblies and accessories. Phil provided an Offshore Wind focussed presentation to our Sales Team. We thank Phil for visiting and updating us on the safety critical role of cable support grips and the need for independent break load testing to safeguard project, people and reputations.
OFFSHORE NETWORKING & THE RENEWABLE REVOLUTION
Thorne & Derrick have joined NOF, a business networking organisation committed to achieving valuable connections between companies in the global energy sector. With an office in North-East England, recognised as a key strategic location to service the offshore renewables energy market in the UK, Thorne & Derrick are currently supplying many international projects from the North Sea to the Nordics, to the USA to China.
Working with Paul Livingstone (Head of Business Development & Membership at NOF) we look forward to maximising the benefits our membership which will include facilitating business introductions, event attendance and utilising their Offshore Wind Projects Database to gain a deep and clear understanding of the offshore wind market through advanced intelligence.
Technical Tip
Featured Jointer
Read | Richie Rice | LS 220kV Cross Bonded Joint XLPE 2500sqmm Copper
Sector Spotlight | Data Centres
Thorne & Derrick supply LV HV Cable Accessories, Installation & Electrical Equipment to service providers working on hyper-scale data centres including Equinix, Virtus, K2, Microsoft, CyrusOne and Interxion. We have recently supplied Warsaw RDCC (Rapid Deployment Data Centres) with sealing systems for the protection of cable ducts against water ingress/gas migration and cable termination products for the connection of 33kV power cables switchgear and transformers – the project is part of a $1 billion digital transformation plan for Poland announced by Microsoft.
We can assist with the Competitive Supply & Technical Specification of joints, terminations and connectors for the energisation of all types of air or gas insulated electrical equipment from stock up to 33kV.
Industry event
Energy Network Events exists to safely promote and further the interests of everyone working in and supplying the electricity industry. The management team have years of experience working in industry, organising and promoting events and use their experience and contacts to win the support of Legislators, Regulators, Senior Managers, World Class Suppliers and Inspirational Figures.
Visit
ENERGYx2022 Visitor Delegate FREE Tickets
Exhibit
ENERGYx2022 South Exhibitor Booking Form
ENERGYx2022 is the industry-leading Exhibition & Conference for anyone working within the Electricity Industry.
Jobs
Cable Jointer (ENW Authorised)
Electricity North West (ENW) is the power network operator (DNO) for the North West of England – they look after the overhead lines, underground cables and substations within their electricity network region.
