Cable Pulling Machine | Southwire Maxis XD10 EXTREME Duty Cable Puller
Published 06 Oct 2020
Cable Pulling Machines
Southwire Maxis XD10
EXTREME Duty Cable Puller
The Southwire Maxis XD10 EXTREME Duty Cable Puller is a cable pulling machine designed to get the job done, thriving in the most extreme cable pulling conditions – XD10 from Southwire allows you to pull cable faster and safer up to 10,000 lbs.
Designed and manufactured in the USA by Southwire and distributed in the UK by Thorne & Derrick – contact us for further information or to discuss a potential cable pulling or installation application.
Cable Pulling Machine – Southwire Maxis XD10 EXTREME Duty Cable Puller
Southwire Maxis XD10 Cable Puller Features
- 10,000 lbs peak cable pulling force with a continuous pulling rating of 7,000 lbs
- High capacity: powerful gear box operates under heavy loads with maximum output
- Self contained: ready to pull cable with no need for additional parts to use for set up
- Single person set up: quickly adapts from underground cable to overhead pulls
- Smooth elevation: operates with handle or 18V cordless drill to eliminate cable lifting
- Collapsible down to 40″H x 26″W x 70″L for ease of transport and site location
âž¡ Best in Class rope guide and capstan prevents rope binding, the XD10 is ready to pull with no additional parts.
Southwire Maxis XD10 EXTREME Duty Cable Puller – Technical Specification
| Southwire Model | Cable Puller Description | Height | Width | Length | Weight |
| XD10 | Maxis XD10 EXTREME Duty Cable Puller | 40″ | 26″ | 70″ | 598 lbs |
| XD-10-BD | XD10-BD Maxis XD10 Bolt Down Kit | 18″ | 14″ | 16″ | 35 lbs |
Capacity – Cable Pulling Speed Low
- At 2,000 lbs 11fpm
- At 4,000 lbs 10fpm
- At 6,000 lbs 9fpm
- At 7,000 lb 8fpm
- At 10,000 lbs 7fpm
Cable Pulling Speed High
- At 2,000 lbs 20fpm
- At 4,000 lbs 18fpm
Southwire
Southwire is one of the world’s leading developers, manufacturers and suppliers of building wire and utility cable, as well as the cable tools used in their installation. As such, Southwire is continually improving its cable products, studying how they’re used in the field and assessing the needs of its customers to find new and better ways to solve the problems facing the industry – this includes underground cables and overhead line conductors.
THORNE & DERRICK
Cable Pulling Equipment
Thorne & Derrick distribute an extensive range of Cable Pulling & Laying Equipment to enable the safe installation of fibre and copper cables within the telecommunications industry. Safely installed cables reduces operational and maintenance requirements to the network and reduced service interruption to telecom cables, wires, ducts, cabinets and exchanges – products include cable spiking tools, conduit rods, cable lubricant, cable socks and cable rollers.
