33kV MV HV Cables – Medium & High Voltage Power Cables PILC
33kV MV HV Cables
PILC
Contact Thorne & Derrick for competitive prices and UK or international delivery on the complete range of 33kV cables with paper insulation (PILC) for medium/high voltage (MV-HV) power systems manufactured by TF Kable.
MV HV cables are available manufactured to DIN VDE 0276- 621, HD 621 S1:1996, BS 6480:1988 and other international cable standards – this includes paper insulated cables with single or 3 core construction, steel wire armour/steel tape armour and lead sheath covered, cables manufactured with both copper or aluminium conductors.
The following table provides an overview of the 33kV MV HV Cable product range for medium voltage paper insulated power cables – a complete range of MV HV Joints & Terminations are also available for 33kV cables.
Joints, Terminations & Connectors For PILC Cables
Complete range of utility approved cable accessories manufactured by 3M, Pfisterer, Nexans Euromold and Prysmian to joint, terminate and connect MV-HV cables up to 33kV with paper insulation.
➡ 33kV Termintions Heat Shrink | 33kV Joints Cold Shrink | 33kV Separable Connectors
Cable Designation | Cable Standard | Nominal Voltage (kV) | Number of Cores | Cross Sections (mm2) | MV HV Application | |
Cu/PILC/JB/DSTA/JS Cu/PILC/JB/DSTA/PVC Al/PILC/JB/DSTA/JS Al/PILC/JB/DSTA/PVC NKRA NAKRA Cu/PILC/JB/SWA/JS Al/PILC/JB/SWA/JS NKFY NAKFY NKRY NAKRY |
DIN VDE 0276- 621 HD 621 S1:1996 parts 1,2,3C,4C BS 6480:1988 SABS 97:2001 AS1026-1992 CAN/CSAC68.1- 92 |
3,3/3,3 3,5/6,0 3,8/6,6 5,8/10 6,35/11 6,6/6,6 11/11 |
3 | 35 ÷ 300 | Paper insulated lead sheathed, steel tapes or wires armoured and PVC or fibrous sheathed power cables for power networks, underground, outdoors, indoors and in cable ducts. |
|
Al/PILC/JB/SWA/JS Cu/PILC/JB/SWA/JS NHKBA NAHKBA Cu/PILC/JB/DSTA/JS Al/PILC/JB/DSTA/JS |
HD 621:1996 parts 1,2,3C,4C DIN VDE 0276-621 BS 6480:1988 SABS 97:2001 AS 1026-1992 |
6,35/11 11,6/20 12,7/22 17,3/30 19,0/33 |
3 | 35÷300 | Paper insulated lead sheathed, steel tapes or wires armoured and PVC or fibrous sheathed radial field power cables for power networks, underground, outdoors, indoors and in cable ducts. |
|
NHKY NAHKY |
DIN VDE 0255 BS 6480 SABS 97 |
3,8/6,6 6,35/11 11,6/20 17,3/20 12,7/22 19,0/33 |
1 | 50÷500 | Paper insulated lead sheathed and PVC sheathed, single core power cables for power networks, underground, outdoors, indoors and in cable ducts. 33kV MV HV Cable. |
