3M Scotch Insulation Tapes

View Sub Products

3M Scotch Electrical Tapes

3M Scotch Electrical Tapes

Scotch Tapes

T&D are Main UK Stockists for 3M Scotch Insulation Tapes – for complete specification, technical and ordering details about 3M insulation tapes please refer to the product sections below.

From stock at competitive prices we can supply the following 3M Scotch Tapes:

  • Scotch 33
  • Scotch 33+
  • Scotch 88
  • Scotch 22
  • Scotch 35
  • Scotch 780
  • Scotch 2510
  • Temflex 1500

Over 30 types of 3M Scotch Insulation Tapes are available offering exceptional performance and reliability for nearly every electrical application – the 3M range includes PVC insulation tapes that provide dielectric strength as well as resistance to moisture, UV, abrasion, corrosion, alkalis and acids.

Insulation Tapes

For High Temperature Applications

For high temperature electrical insulation and applications up to 130°C (Class B – Scotch 27) see the range of glass cloth tapes for excellent mechanical strength. Class H temperature class (180°C) glass cloth tapes are also available, see Scotch 69.

3M Scotch PVC Insulation Tapes provide primary electrical insulation up to 600 volts and are used in jacketing applications for low-high voltage cables and wire harnessing.

All 3M Electrical Tapes are suitable for electrical insulation, cable jointing, corrosion protection, environmental sealing and general purpose low and high voltage electrical taping applications for LV, MV, HV 3.3kV, 6.6kV, 11kV and 33kV.

➡ For details on the complete range of 3M insulation, self-amalgamating, mastic sealing, corrosion and fire protection tapes for LV-MV-HV cable jointing, terminating and insulating applications please see 3M Scotch Electrical Tapes.

3M Scotch Electrical Tapes - 3M Scotch Insulation Tapes

Scotch Electrical Tapes

Suppliers & Stockists of 3M Scotch Electrical Tapes | Scotchcast Resins | Cold Shrink Products | UK & Export Sales

3M Scotch Premium Electrical Insulation Tapes

3M Scotch Tape 3M Scotch Tape Part Number  Tape Thickness  Temperature Rating  Roll Size
3M Scotch Super 88 Tape 3M Scotch Super 88   0.216mm -18ºC to +105°C 19mm x 20m
25mm x 20m
38mm x 20m
3M Scotch 33 Tape - ex stock 3M Scotch 33 0.178mm 0ºC to 80ºC 9mm x 33m
12.7mm x 33m
19mm x 33m
25mm x 33m
38mm x 33m
50mm x 33m
3M Scotch 35 Tape 3M Scotch 35  0.178mm 0°C to 80ºC  19mm x 20m
3M Scotch 22 Tape 3M Scotch 22  0.254mm -10ºC to +80°C 12mm x 33m
19mm x 33m
25mm x 33m
38mm x 33m
50mm x 33m
3M Scotch 700 Tape 3M Scotch 780  0.18mm -10ºC to +80°C  19mm x 20m
3M Scotch 2510 Tape 3M Scotch 2510   0.18mm -18ºC to +105°C  19mm x 20m
3M Temflex 1500 Tape 3M Temflex 1500 0.15mm 0ºC to 90ºC 19mm x 25m

➡ T&D stock and supply the complete range of 3M Scotch Insulation Tapes.3M Scotch Insulation Tapes

3M Scotch Electrical tapes are used to cable joint, splice, repair, seal and protect cables against abrasion, fire and corrosion – this includes LV-HV (11kV-33kV cables) – please contact T&D should you require assistance with selecting the correct tape.

3M Tapes

The following gallery of 3M Scotch Tapes including insulation tapes demonstrates the diversity of applications to provide electrical insulation and protection to cables operating at low, medium and high voltages:

Complete range of 3M Cable Accessories for the repair, joint and termination of LV MV HV cables.
