ALROC MF2/60

Alroc MF2/60 cable tools are used by MV-HV jointers to remove the outer sheath and insulation to prepare the cable ready for the installation of joints, terminations or connectors.

The MF2/60 allows the user to remove the outer sheath (PE-PVC-PR) with a straight and neat cut and set the length to be removed and remove the insulation with a straight and neat cut.

Tuning of the pitch of the tool embedded wear pads to protect the tool from the contact with the outer sheath

MF2/60 MV HV Cable Jointing Tool

MF2/60 MV HV Cable Jointing Tool

Alroc MF2/60 – Technical Specification

Cable Tool Part Number Diameter Tool Capacity Dimensions Packaging
Outer sheath and insulation thickness capacity Length Width Height
Alroc MF2/40 16 – 40 mm 0,630 – 1,575 in 7 mm  / 0,275 mm 150 mm 5,906 in 80 mm 3,150 in 100 mm 3,937 in None
Alroc MF2/40-S 16 – 40 mm 0,630 – 1,575 in 7 mm / 0,433 in 150 mm 5,906 in 80 mm 3,150 in 100 mm 3,937 in None
Alroc MF2/60 16 – 58 mm 0,630 – 2,283 in 11 mm  / 0,275 mm 170 mm 6,693 in 90 mm 3,543 in 120 mm 4,724 in None
Alroc MF2/60-S 16 – 58 mm 0,630 – 2,283 in 11 mm / 0,433 in 170 mm 6,693 in 90 mm 3,543 in 120 mm 4,724 in None
