Alroc OGA | Cable Outersheath & Jacket Stripper Removal Tool
Cable Sheath Stripping Tools
Alroc OGA
The OGA heavy duty cable outersheath removal tool is manufactured by Alroc and enables a longitudinal and circumferential (“ring”) cut to be made on the outer sheath of single and multi-core cables by the cable jointer. These cable stripping tools feature four different cutting thickness positions and two cutting edges on the same cutting blade to give the jointers tools an extended working life – suitable for MV HV cable stripping up to 200mm outer sheath cable diameters (5mm cable sheath thickness maximum).
Alroc OGA
Cable Tool Specifications
| Order Code | Tool Description | Diameter | Cable Dimensions | Weight (without box) | Packaging | ||
| Length | Width | Height | |||||
| Alroc OGA | MV Cable Tools – Outer Sheath Opener | 20 – 200 mm 0,787 – 7,874 in |
180 mm 7,087 in |
26 mm 1,024 in |
62 mm 2,441 in |
0,27 Kg | Case |
Alroc Tools – Cable Jointing Tools (MV HV)
cABLE JOINTERS TOOLS
MV HV EHV
- MVÂ Medium Voltage Cables 11kV 33kV
- HVÂ High Voltage Cables 66kV
- EHVÂ Extra High Voltage Transmission & Distribution Cables 132kV 245kV 400kV
 For further information about Alroc cable tools for removing cable screen from MV-HV cables please see below.
T&D also distribute Cembre and Klauke tools for cable cutting and cable crimping of copper and aluminium conductors.
Cable Innovation Tools & Accessories for Low & High Voltage Power Systems | Thorne & Derrick are Specialist Distributors of LV HV Cable Jointing, Earthing, Substation & Electrical Eqpt up to 66kV – this includes the most extensive range of Ex Stock Innovation Tooling to facilitate safe and reliable preparation, termination and installation of cables.
Data Sheet | Alroc OGA Cable Outersheath & Jacket Stripper Removal ToolDownload
