BR1 Bar to Earth Rod

BR1

BR1

  • Product Category: Exothermic Welding
  • Order Code: BR1
  • Application: Bar to Earth Rod Exothermic Welding Connector

Used to weld flat copper tape conductors according to the sizes in the selection table below.

âž¡ Complete range of Earthing & Lightning Protection products manufactured from copper including earth rods, bars, tapes, clamps and ancillary items.

A Earth Rod mm B Earth Rod inches C Conductor mm x mm Weld Powder Exothermic Welding Mould Handle Clamp
12.7 1/2″ 20 x 3 WEP 090 BR1-C-127203 HCC 001
25 x 3 BR1-C-127253
25 x 4 BR1-C-127254
30 x 2 BR1-C-127302
30 x 3 BR1-C-127303
31 x 3 BR1-C-127313
38 x 3 BR1-C-127383
40 x 3 BR1-C-127403
50 x 3 WEP 115 BR1-C-127503
50 x 6 BR1-C-127506
14.2 5/8″ 20 x 3 WEP 090 BR1-C-142203 HCC 001
25 x 3 BR1-C-142253
25 x 4 WEP 115 BR1-C-142254
25 x 6 BR1-C-142256
30 x 2 BR1-C-142302
30 x 3 BR1-C-142303
30 x 4 WEP 150 BR1-C-142304
30 x 5 BR1-C-142305
31 x 3 WEP 115 BR1-C-142313
31 x 6 WEP 150 BR1-C-142316
38 x 3 WEP 115 BR1-C-142383
38 x 5 WEP 150 BR1-C-142385
38 x 6 WEP 200 BR1-C-142383
40 x 3 WEP 115 BR1-C-142403
40 x 4 WEP 150 BR1-C-142404
40 x 5 BR1-C-142405
40 x 6 WEP 200 BR1-C-142406
50 x 3 WEP 150 BR1-C-142503
50 x 4 WEP 200 BR1-C-142504
50 x 5 BR1-C-142505
50 X 6 BR1-C-142506
17.2 3/4″ 20 x 3 WEP 115 BR1-C-172203 HCC 001
25 x 3 WEP 150 BR1-C-172253
25 x 4 BR1-C-172254
25 x 6 WEP 200 BR1-C-172256
30 x 2 WEP 150 BR1-C-172302
30 x 3 BR1-C-172303
30 x 4 WEP 250 BR1-C-172304
30 x 5 WEP 200 BR1-C-172305
31 x 3 WEP 150 BR1-C-172313
31 x 6 WEP 250 BR1-C-172316
38 x 3 WEP 200 BR1-C-172383
38 x 5 BR1-C-172385
38 x 6 2 x WEP 150 BR1-D-172386 HCD 001
40 x 3 WEP 200 BR1-C-172403 HCC 001
40 x 4 BR1-C-172404
40 x 5 BR1-D-172405 HCD 001
40 x 6 2 x WEP 150 BR1-D-172406
50 x 3 BR1-D-172503
50 x 4 BR1-D-172504
50 x 5 BR1-D-172505
50 x 6 2 x WEP 200 BR1-D-172506
50 x 8 BR1-D-172508
