Cembre B-TC500YE Battery Cable Cutting Tool

Cembre B-TC500YE Battery Cable Cutting Tool

Cembre B-TC500YE Battery Cable Cutting Tool

LV-HV Cable Cutting Tools For Copper, Aluminium, Aluminum-Steel cables (ACSR)

B-TC500YE

Cembre B-TC500YE battery cutting tools are designed for use by LV-HV cable jointers, overhead linesmen and electrical engineers for cutting copper, aluminium and ACSR cables with a maximum overall cable diameter of 50mm.

Cembre cutting tool blades are manufactured from high strength steel and heat treated to ensure extended service life – the cable cutting tool head rotates through 90 degrees enabling the user to cut cables in the most comfortable position and can be opened easily to allow cutting of running cables.

The Cembre B-TC500YE cutting tool is fitted with a maximum hydraulic pressure valve.

Cembre B-TC500YE cutting tool

Specification

  • Max Cutting Diameter: 50mm
  • Rated Operating Pressure: 700 bar (10,000 psi)
  • Dimensions: 405mm x 398mm x 83mm
  • Cable Cutter Weight: 5.8kg
  • Oil: AGIP ARNICA 32 or equivalent (Approved by Cembre)

Cembre cutting tools should be cleaned daily (or after use) with a clean cloth removing any residue in particular particles close to pivots and moveable parts. Every six months it is essential check the oil level in the reservoir. If necessary fill oil level to the top lip and remove any excess air from the reservoir.

The cutting tool is supplied as:

  • Basic tool with battery and shoulder strap
  • Spare battery
  • Battery charger
  • Plastic carrying case suitable for storing the tool and accessories

For storage and protection the Cembre B-TC500YE tool is supplied in a robust carrying bag for storage of the cutting tool.

  • Dimensions 520x432x126 mm



B-TC500YE Dimensions

Max cutting Ø mm Length Height Width Weight
50 405mm 398mm 83mm 5.8kg

Cembre B-TC500YE Cutting Tool

battery operated

Technical Specification

Cembre B-TC500YE use Li-Ion 18 V 4 Ah batteries offering a higher capacity than 14.4 V 3 Ah, while greater cutting speed and cutting force result from a powerful hydraulic cable cutting system with double speed action. The battery is equipped with LED indicators to show the remaining battery life at any time by pressing the adjacent button.

Cembre tools are designed with improved balance – Cembre B-TC500YE is easily manageable during the cable cutting process has a shell with high resistance to wear and damage.

Rubber grip inserts, low noise and minimal vibration aid operator comfort while additional convenience and safety are provided by LED lighting of the working area.

Cembre B-TC500YE Battery Cable Cutting Tool

Cembre Tool Type B-TC500YE Cable Cutter (Hydraulic – Battery Operated)
Battery Material Li-Ion
Battery Voltage 18 V
Battery Current 4 Ah
Maximum Cable Cutting Diameter 50mm
Length 405mm
Width 83mm
Height 398mm
Weight 5.8kg
Cembre B-TC500YE Tool | Cable Cutting Tool | Battery Operated Cable Cutter

Cembre B-TC500YE Tool | Cable Cutting Tool | Battery Operated Cable Cutter

Cable Cutting Safety

Keep hands clear from cutting blades ♦ Do not cut steel ♦ Wear safety glasses and gloves ♦ Read tool instructions prior to cutting cable
