Cembre B-TC650E Cutting Tool 65mm (Overhead Lines – Copper & Aluminium)

Cembre B-TC650E Cutting Tool - Battery Operated

Cembre B-TC650E Cutting Tool – Battery Operated

LV-HV Cable Cutting Tools For Copper, Aluminium & Telecommunication Cables

B-TC650E

Cembre B-TC650E battery cutting tools are designed for use by LV-HV cable jointers, overhead linesmen and electrical engineers for cutting copper, aluminium and telecommunication cables with a maximum overall cable diameter of 65mm.

Cembre cutting tool blades are manufactured from high strength steel and heat treated to ensure extended service life – the cable cutting tool head rotates through 335 degrees enabling the user to cut cables in the most comfortable position and can be opened easily to allow cutting of running cables.

The Cembre B-TC650E cutting tool is fitted with a maximum hydraulic pressure valve and has an operating temperature of +5 °C to +122 °C.

Cembre B-TC650E cutting tool

Specification

  • Max Cutting Diameter: 50mm
  • Rated Operating Pressure: 600 bar (8,700 psi)
  • Dimensions: 405mm x 398mm x 83mm
  • Cable Cutter Weight: 5.8kg
  • Oil: AGIP ARNICA 32 or equivalent (Approved by Cembre)

Cembre cutting tools should be cleaned daily (or after use) with a clean cloth removing any residue in particular particles close to pivots and moveable parts. Every six months it is essential check the oil level in the reservoir. If necessary fill oil level to the top lip and remove any excess air from the reservoir.

The cutting tool is supplied as:

  • Basic tool with battery and shoulder strap
  • Spare battery
  • Battery charger
  • Plastic carrying case suitable for storing the tool and accessories

For storage and protection the Cembre B-TC650E tool is supplied in a robust carrying bag for storage of the cutting tool.

  • Dimensions 520x432x126 mm

B-TC650E Dimensions

Max cutting Ø mm Length Height Width Weight
65 429mm 415mm 83mm 6.4kg

CEMBRE B-TC650E CUTTING TOOL

BATTERY OPERATED

TECHNICAL SPECIFICATION

Cembre B-TC650E use Li-Ion 18 V 4 Ah batteries offering a higher capacity than 14.4 V 3 Ah, while greater cutting speed and cutting force result from a powerful hydraulic cable cutting system with double speed action. The battery is equipped with LED indicators to show the remaining battery life at any time by pressing the adjacent button.

Cembre tools are designed with improved balance – Cembre B-TC650E is easily manageable during the cable cutting process has a shell with high resistance to wear and damage.

Rubber grip inserts, low noise and minimal vibration aid operator comfort while additional convenience and safety are provided by LED lighting of the working area.Cembre B-TC650

Cembre Tool Type B-TC650E Cable Cutter (Hydraulic – Battery Operated)
Battery Material Li-Ion
Battery Voltage 18 V
Battery Current 4 Ah
Maximum Cable Cutting Diameter 65mm
Length 83mm
Width 415mm
Height 429mm
Weight 6.4kg
Cembre B-TC650E Tool | Cable Cutting Tool | Battery Operated Cable Cutter

Cembre B-TC650E Tool | Cable Cutting Tool | Battery Operated Cable Cutter

Cembre B-TC650E

Cembre B-TC650E Cutting Tool

Cembre B-TC650E Cutting Tool

  1. LED worklight
  2. Upper cutting blade
  3. Lower cutting blade
  4. Latch
  5. Operating button
  6. Pressure relelase button
  7. Battery
  8. Battery capacity indicator
  9. Battery check button
  10. Battery release
  11. Ring for shoulder strap
  • Order Ref : Cembre B-TC650E



Cable Cutting Safety

Keep hands clear from cutting blades ♦ Do not cut steel ♦ Wear safety glasses and gloves ♦ Read tool instructions prior to cutting cable

B-TC650E – Maintenance

The tool is robust, completely sealed, and requires very little daily maintenance. Compliance with the following points, should help to maintain its optimum performance:

Thorough cleaning

  • Dust, sand and dirt are a danger for any hydraulic device. Every day, after use, the tool must be wiped with a clean cloth taking care to remove any residue, especially close to pivots and move­able parts.

Do not use hydrocarbons to clean the rubber parts.

  • Regularly lubricate the moving parts and pivot pins of the head with a few drops of oil.

Storage Case

When not in use, the tool should be stored and transported in the plastic case, to prevent damage. The case, type VAL-P40, is suitable for storing the tool and accessories.

VAL-P40: Size 520x432x126 mm (20.5×17.0x5.0 inches). Weight 2,6 kg (5.7 Ibs).

Routine Maintenance

When the tool reaches the predetermined number of hours worked, it will signal that routine maintenance is recommended.

Please Note: the tool will continue to work however 15 sec. after use an alarm comprising 3 beeps com­bined with illumination of the worklights will signal that its return to Cembre for service
