CS2 Cable To Steel Surface
CS2
- Product Category: Exothermic Welding
- Order Code: CS2
- Application: Cable to Steel Surface Exothermic Welding Connector
Used to weld copper conductors according to the sizes in the selection table below.
âž¡ Complete range of Earthing & Lightning Protection products manufactured from copper including earth rods, bars, tapes, clamps and ancillary items.
| A Conductor sqmm | Weld Powder | Exothermic Welding Mould | Handle Clamp |
| 16 | USE MOULD TYPE CS9 | ||
| 25 | |||
| 35 | |||
| 8mm ∅ | WEP 090 | CS2-C-8SC | HCC 001 |
| 50 | CS2-C-50 | ||
| 70 | WEP 115 | CS2-C-70 | |
| 95 | CS2-C-95 | ||
| 120 | WEP 150 | CS2-C-120 | |
| 150 | WEP 200 | CS2-C-150 | |
| 185 | WEP 250 | CS2-C-185 | |
| 240 | 2 x WEP 150 | CS2-D-240 | HCD 001 |
| 300 | 2 x WEP 200 | CS2-D-300 | |
