NA2XS(F)2Y RM 18/30kV XLPE Medium Voltage Cable
30kV MV XLPE cable
NA2XS(F)2Y RM
NA2XS(F)2Y RM Cable Description: Single-core XLPE-insulated cables with PE sheath, longitudinally watertight, manufactured by Nexans.
International Standards:Â IECÂ 60502-2
Description: Solid aluminium conductor – conductor screen of semiconducting compound – insulation of cross-linked polyethylene (XLPE) – screen of semiconducting compound – semiconducting swellable tape – screen of copper wires and copper tape – separation tape – PE sheath. The high voltage cable is suitable for rated voltage 18/30KV according to IEC 60502-2.
Application: in ground, outdoors, in water, indoors and in cable ducts. This product is also part of the Nexans Windlink® range, dedicated to wind turbines.
♦ See Cable Jointing Tools to enable cable sheath, semi-con screen and insulation removal of Nexans NA2XS(F)2Y RM cables.
NA2XS(F)2Y RM Single Core Cable
Specification
| Construction Characteristics | |
| Lead Free | Yes |
| Halogen Free | Yes |
| Longitudinally Watertight | Yes |
| Conductor Shape | Circular stranded (RM) |
| Insulation | XLPE (chemical) |
| Material of Bedding | SC swelling tape |
| Screen | Â Copper wire + Copper tape |
| Outer Sheath | PE |
| Sheath Colour | Black |
| Usage Characteristics | |
| Minimum Operating Temperature | -40 °C |
| Minimum Installation Temperature | -20 °C |
| Maximum Conductor Temperature in Service | 90 °C |
| Short-Circuit Maximum Conductor Temperature | 250 °C |
| Bending Factor When Laying | 15 (xD) |
| Packaging | Drum |
Nexans manufacture an extensive range of MV & HV Cables, 11kV, 33V & 66kV
âž¡ See HV Cable Joints, Terminations & Connectors to enable the installation of NA2XS(F)2Y RM 18/30kV XLPE Medium Voltage Cable – for terminating
medium voltage cables into MV-HV gas insulated switchgear, transformers and electrical equipment with outer cone type bushings please see Nexans Euromold connectors – slip-on, heat shrink terminations and cold shrink cable joints from 11kV-33kV (42kV) also available for MV-HV cables.
Nexans Euromold screened separable connectors, elbows and Tee-connectors terminate high voltage cables with polymeric insulation (XLPE & EPR) onto switchgear and transformer bushings.
