Dry Cable Terminations Up To 170kV

IXOSIL is based on standard High Voltage Cable Accessory product design that have been established on the market for many years, using tried-and tested materials and field-proven technologies – lightweight, compact design, the dry-insulated terminations are easy to install, requiring very little space.

The flexible IXOSIL ESF EST by PFISTERER can be integrated in existing fixing points and is particularly suitable for flexible quick-insulation multiple-use applications in testing or temporary site cables. ESF was designed for the high voltage range between 52kV and 170kV.

For many years dry-type outdoor cable terminations have been used worldwide in substations and on high-voltage transmission towers. Reliable in long term use, the cable terminations connect cable systems with overhead lines and busbars. The range covers voltage levels from 52kV to 170kV and includes 3 product versions: a self-supporting cable termination with or without integral surge arrester, and a flexible cable termination. This enables a cost-effective solution of exactly the right size to be realised for every requirement and environmental situation.

PFISTERER also have a integrated arrester solution the IXOSIL EST SUB. The surge arrester is used as the fixing point for the cable termination and eliminates the need of any additional supporting or connecting devices.

Pfisterer Ixosil ESF EST

Dry Type Outdoor Cable Terminations

Dry-type outdoor cable terminations are the technology for the future – geared toward stable networks and a secure power supply. All products are insulated exclusively with solid silicone.

The dry-type IXOSIL range terminations contain no liquid, they are lighter and easier to transport and, what is more, they are quicker to install than conventional terminations.

Pfisterer IXOSIL ESF / EST Terminations

IXOSIL ESF 52-170kV – dry flexible cable terminations
IXOSIL EST SUB 72-170kV – dry self-supporting for high voltage substations
IXOSIL EST 72-170kV – dry self-supporting terminations for towers
IXOSIL EST SUB SA/SAC 123-170kV – dry self-supporting with integrated high voltage surge arrester

High Voltage Dry Type Termination Benefits

No costs for scaffolding on account of simple assembly on the ground
Short downtimes thanks to efficient installation
Safe and easy installation on the ground
High degree of termination reliability (explosion-proof)
No liquid or gaseous insulation materials
High cost-cutting potential compared to conventional terminations

Contact Thorne & Derrick for assistance with the Design, Specification, Selection or Supply of HV Cable Accessories to enable the jointing, termination, connection or sealing of power cables at 66kV/132kV/170kV – Thorne & Derrick also distribute the most extensive range of MV Medium Cable Joints, Terminations & Connectors (11kV/33kV) from manufacturers including 3M, Prysmian, Nexans Euromold, Elastimold, Pfisterer CONNEX & SEANEX.

Heat shrink, cold shrink, push-on and slip-over cable accessories enable the jointing, terminating and connection of 11kV-33kV and 66kV cables to oil, air or gas insulated switchgear, transformers, turbines, motors and overhead lines distributing electricity at medium/high voltages.

More High Voltage Cable Terminations from PFISTERER

PFISTERER dry cable terminations

PFISTERER dry cable terminations are proven and well-thought-out products for substations and high voltage transmission towers at voltage levels from 52kV to 170kV.

Variants include self-supporting cable terminations, flexible cable terminations and terminations with integrated surge protection. With this portfolio, custom requirements can be implemented extremely cost-effectively, and precisely matched to the respective location.
