36 Piece Jointer’s Tool Kit 4

Tool Kit 4, manufactured by Boddingtons Electrical, contains a set of 36 insulated tools for Cable Jointers for live line working and electrical safety. Tools are insulated according to IEC 60900 and usable up to 1000 V AC/1500 V DC.

Boddingtons Electrical

Cable Jointer’s Tool Kit 4

Contents

Tool Part Number Description
103075 Insulated Hybrid Neutral Cable Wedge, 130mm Length
236316 Insulated Diagonal Side Cutter, >4mm ⌀ Cutting Rates, 160mm Length
292630 Insulated Groove Joint Pliers, 300 mm Length
430315 Insulated Depth Armour Gauge Saw, 150 mm Length of Blade
525003 Plastic 2m Folding Rule
599T05 LV Pocket Shroud, Type 5 General Purpose Cover , 250 x 450mm
651409 Insulated Safety Clamps with Rubber Contacts in Jaw To Protect Insulating Material, 45mm Opening, 140mm Length, 85mm Width
701150 Insulated Junior Hacksaw with a 32 TPI Blade, 150mm Blade Length
701300 Insulated HackSaw with 24 TPI Blade, 480mm Overall Length, 300mm Blade Length
JTN-1 Non Conductive Insulating Mini Hepwedge Core Separator, 130mm Length
JTN-2 Non Conductive Insulating Midi Hepwedge Core Separator, 160mm Length
JTN-3 Non Conductive Insulating Maxi Hepwedge Core Separator, 262mm Length
JTN-4 Non Conductive Insulating Plastic HEPNYF Hack Knife, 245mm Overall Length
PA1968/10 Heavy Duty Insulated Cable Cutter – EL Type , 25 mm2 Material Cross Section, 250mm Length
124510 Tin English Pattern Snips 250mm Length
PPHRSC10 Half Round Second Cut Engineers File 250mm
PPRSC8 Round Second Cut Engineers File 200m
216320 Insulated Combination Pliers, 200 mm Length, Cutting Rates ⌀ 13mm Soft Wire
151319 Insulated Open Ended Spanners – Metric/Whitworth/A/F 175mm Length, Size 19mm
1103NY Non Conductive Insulating Nylon Cable Core Wedges with Groove, 225mm Length
111310 Insulated Slotted Screwdriver, 10mm Tip Length, 1.6 Tip Width, 200mm Blade Length
111354 Insulated Slotted Screwdriver, 5.5mm Tip Length, 1.0 Tip Width, 150mm Blade Length
114302 PZ Insulated Pozidrive Screwdrivers , PZ2, 100mm Blade Length, 210mm Overall Length
115303 Insulated Allen Key ScrewDrivers for Hexagon Screws, 3mm Point Size, 80mm Blade Length, 170mm Overall Length
124510 Tin English Pattern Snips 250mm Length
130413 Insulated 6 Point Socket 1/2″ Square Drive Standard for Hexagon Bolts, 50mm Length, 13mm Size
130417 Insulated 6 Point Socket 1/2″ Square Drive Standard for Hexagon Bolts, 50mm Length, 17mm Size
130418 Insulated 6 Point Socket 1/2″ Square Drive Standard for Hexagon Bolts, 50mm Length, 18mm Size
130419 Insulated 6 Point Socket 1/2″ Square Drive Standard for Hexagon Bolts, 50mm Length, 19mm Size
131312 Insulated 1/2″ Square Drive Reversible Ratchet Lever, 260mm Length, 85mm Height
133312 Insulated 1/2″ Square Drive Extension Bar, 125mm Length
136908 Insulated Nut Spinners 8.00mm Point Size, 125 Blade Length, 225mm Overall Length
150716 Insulated Open Ended Spanners – Whitworth 200mm Length, Size 7/16 W
151313 Insulated Open Ended Spanners – Metric/Whitworth/A/F 135mm Length, Size 13mm
151317 Insulated Open Ended Spanners – Metric/Whitworth/A/F 155mm Length, Size 17mm
TCC/C Straight-Through Joint (Two Way Connectors) , 1.22m Minimum Span with 2 Braids

Live Working Insulated Tools

Insulated tools are used by utility contractors for safe cable preparation, jointing and working on waveform, wavecon, paper/lead low voltage distribution cables – see also cable jointing tools for stripping, cutting and removing sheath, insulation and screen from LV-HV cables.
