Interface C Connectors

Interface C Symmetrical – Nexans Euromold Connectors, Plugs, Elbows, Bushings & Surge Arresters

Nexans Euromold Interface C Symmetrical separable connectors for terminating MV-HV cables (including XLPE EPR 11kV 17.5kV, 24kV) – a complete range of elbow & tee connectors for termination of medium/high voltage cables into switchgear, transformers, motors and substations up to 42kV

Full supporting range of Euromold elbow 24kV connectors, tee connectors, coupling connector, surge arresters, test rods, installation tools and bushings suitable for Interface C bushings according to CENELEC EN 50180 and 50181.

Euromold Interface C Symmetrical connectors are suitable for termination of polymeric (XLPE EPR) insulated cables with copper wire or tape screen, wire armoured (SWA/AWA), wire braided or unarmoured cables into MV-HV Electrical Equipment with Interface C bushings.

  • 6/10kV (12kV)
  • 6.35/11kV (12kV)
  • 8.7/15kV (17.5kV)
  • 12/20kV (24kV)
  • 12.7/22 (24kV)
  • 18/30 (36kV)
  • 19/33 (36kV)
  • Up to 42kV 630 Amps 800 Amps

Blog: Euromold 600 Series Connectors Symmetrical | Interface C Bushings

Interface C Connectors & MV HV Euromold Products

  • Euromold 480TB Tee Connector
  • Euromold 400LB Elbow Connector
  • Euromold 400TB Tee Connector
  • Euromold 440TB Tee Connector
  • Euromold 440PB Coupling Connector
  • Euromold 400PB – XSA Surge Arrester
  • Euromold 400TR and 400TR-LB Test Rods
  • Euromold 400TK and 400SW Installation Tools

33kV Connectors Interface C

Short Circuit Ratings

C1

  • Contact Type – Bolted
  • Connector Current Rating – 630A
  • RMS Symm
    1 Sec – 28.0kA
    2 Sec – 19.7kA
    3 Sec – 16.1kA
  • Peak Asymm – 70kA
  • Cable Connector Voltage Um – 36kV

C2

  • Contact Type – Bolted
  • Connector Current Rating – 1250A
  • RMS Symm
    1 Sec – 75.0kA
    2 Sec – 53.0kA
    3 Sec – 16.1kA
  • Peak Asymm – >150kA
  • Cable Connector Voltage Um – 36kV

Euromold 400LB Elbow Connectors Up to 24kV 630A

Euromold Separable
Connector
Sype
Voltage
Um
(kV)
Current Ir (A) Conductor Sizes (sqmm)
min max
400LB/G 12kV 630 Amps 25 300
K400LB/G 24kV 630 Amps 25 300



Euromold 400LB Ordering Instructions

Select the Nexans Euromold connector part number from the below table which provides the best centring to the cable core insulation diameter. For 24kV connectors add a “K”.

Euromold Connector Order Example – the MV-HV cable to be terminated is XLPE insulation 24kV with 240sqmm stranded copper conductor with a core insulation diameter over the medium/high voltage power cable of 32.2mm. Order Code: Nexans Euromold 3 x K400LB/G-27 connector kit.

Euromold 400LB
Part Number
Dia. over core insulation (mm)
min max
3 x 400LB/G-11 12.0 17.5
3 x 400LB/G-15 16.0 22.0
3 x 400LB/G-19 20.0 26.5
3 x 400LB/G-22 23.5 31.0
3 x 400LB/G-25 26.5 32.5
3 x 400LB/G-27 28.5 37.5



Interface C Bushing Connectors

Full supporting range of Euromold medium voltage accessories for use with Interface C connectors are available.

Nexans Dead-End Receptacles (12kV 400DR-B/G, 24kV K400DR-B/G, 36kV M400DR-B/G)

Receptable used to fit over MV bushings with a type C Interface to provide “dead-end” function. Receptacle available with integral earth lead.

400DR-B/G Euromold

400DR-B/G Euromold

Nexans Euromold 400SOP-B Stand-Off Plugs (12kV 400SOP-B, K400SOP-B 24kV, M400SOP-B 36kV, 42kV P400SOP-B)

Stand-off plugs used to support and “dead-end” connectors with a type C Interface when removed from medium/high voltage electrical equipment.

400SOP-B Euromold

400SOP-B Euromold

Nexans Euromold 400GP-B Earthing Plugs (12kV, 24kV, 36kV, 42kV 400SOP-B)

Earthing plug designed to support and earth Euromold connectors with type C Interface bushings when removed from medium/high voltage equipment.

400GP-B Euromold

400GP-B Euromold

Nexans Euromold 400BIPA Insulating Plugs (12kV 400BIPA, 24kV K400BIPA, 36kV M400BIPA, 42kV P400BIPA)

Acts as a tightening nut for the Euromold 400TE tee connector and 440TB termination – the 400BIPA plug contains a voltage detection point. The conductive rubber protection cap is included.

400BIPA Euromold

400BIPA Euromold

Nexans Euromold 400CP-SC Connecting Plugs (12kV 400CP-SC, 24kV K400CP-SC, 36kV M400CP-SC)

Plugs used for connecting two or more connectors with a type C Interface together and therefore creating a separable cable joint or a multiple cable connection to equipment, including 33kV switchgear.

400CP-SC Euromold

400CP-SC Euromold

Nexans Euromold 400CP Connecting Plugs (12kV 400CP, 24kV K400CP, 36kV M400CP)

Plugs for connecting two or more 440TB connectors therefore creating a separable cable joint or a multiple cable connection to equipment for use up to 1250A. Order (K)(M)440CP + 676SA for connection to an already installed 440TB connector.

400CP Euromold

400CP Euromold

Nexans Euromold 400RTPA Reducing Tap Plugs (12kV 400RTPA, 24kV K400RTPA)

Plugs provide a type A Interface to connectors with a type C interface. A ‘C’ spanner 600SW is used to tighten the reducing tap plug on to its mating part. Order 600SW for the ‘C’ spanner.

400RTPA Euromold

400RTPA Euromold
