Welcome to our industry bulletin – VOLTS.

So what is VOLTS?

VOLTS is our monthly round-up of industry news, projects, videos, technical tips, training information, promotions, webinars and career opportunities from Thorne & Derrick. Take a moment to Follow Us on LinkedIn to receive future VOLTS.

Press Release

In 2018, Thorne & Derrick signed a UK Distribution Agreement with Nexans Power Accessories – this united a leading UK based Specialist Electrical Distributor with the global driver of the world’s transition to a more connected and sustainable energy future.

Since inception our contracted agreement has delivered consecutive annual business growth, last year including a 65% record year-on-year leap in sales.

Press Release | Record Business Growth for Thorne & Derrick and Nexans Power Accessories (UK) Ltd

pROJECTS & NEWS

PADS Approved

Following extensive and successful field trial testing the Nexans Euromold range of Connectors & Bushings have now received Full Acceptance by Network Rail with Official PADS Approval – specifically this includes Nexans Tee Connector model QM909TB Interface F and associated equipment bushing QM909AR. The product authorisation by Network Technical Head Power Distribution HV/LV on behalf of the Network Rail Acceptance Panel (NRAP) permits the installation of the Tee Connectors and Bushings to ground mounted oil filled transformers up to 52kV.

Read Press Release | Network Rail Full Acceptance for Nexans Tee Connectors & Bushings for 25kV Power Transformers

Network Rail Full Acceptance for Nexans Tee Connectors & Bushings for 25kV Power Transformers

Thorne & Derrick supply an extensive range of 400V-33kV Rail Cable Accessories & Power Distribution Systems to contractors undertaking LV Power Distribution, HV Electrification & Substations, DC Traction & Networks, OLE and Track Feeder Cable Renewals.

25kV Switchgear Terminations

25kV Switchgear Terminations | Nexans AFN36-6 42kV single core cable terminations are Network Rail PADS Approved for indoor 25kV air insulated switchgear applications. The cold-applied Slip-on rail cable termination is approved for use with Siemens ASG25 – 25kV air insulated switchgear for AC traction power supply systems.

Thorne & Derrick | Approved PFISTERER Stockist | CONNEX | SEANEX | SICON

Let’s Meet

Throughout March, Thorne & Derrick continued to invite their supply chain to our offices and we also conducted online meetings to ensure staff are up-to-date with product developments, discuss sales-marketing campaigns and strategy plan for the year ahead.

Thorne & Derrick welcomed Karl McFadden (Commercial Sales Manager at PFISTERER) and Drew Houghton (Commercial Sales at PFISTERER) to our offices for product training including an overview of the market-leading and new generation Sicon brand of stepless shearbolt connectors. Additional manufacturer updates included an impressive presentation on the project award at Seagreen with the SEANEX range of dry pluggable high voltage cable connectors for 66kV inter-cable termination.

Thorne & Derrick hold extensive stocks of the MV-CONNEX separable connector range of inner-cone plug type cable connections for use with 33kV electrical equipment – this is supported by the provision of Jointer Competency Training to ensure the reliability of electrical connections.

Blog | Thorne & Derrick | Product Training With PFISTERER

Read Article | SEANEX | PFISTERER Connectors Selected For 66kV Wind Turbine Terminations At Seagreen Project

Thorne & Derrick hold extensive stocks of the MV-CONNEX separable connector range of inner-cone plug type cable connections for use with 33kV electrical equipment - this is supported by the provision of Jointer Competency Training to ensure the reliability of electrical connections.

Sealing Inter-Array Cables

Working with Orsted, Van Oord and the Inter Array Project Manager from LS Cable & System, Thorne & Derrick have specified a cable sealing system to prevent water ingress into the power and fibre optic cores of de-energised high voltage inter-array cables (IAC).

Manufactured by 3M Electrical their range of EC type Cold Shrink cable end caps will provide protection from exposure to moisture, contamination, corrosion, ozone, UV radiation and other environmental hazards.

The proposed product solution was adopted based upon safe working procedure, field service history and product testing according to ASTM D 412-75: – the Cold Shrink technology cable caps are a flame-free and tool-less installation.

The 3M EC-4 type cap will be applied to protect and seal the exposed power core cable ends following the cable pull-in in general accordance with the installation process outlined in the video below – these will be mounted by the Cable Installation Contractor on the wind turbine foundation and offshore substation (OSS) after removal of excess pull-in lengths.

The fibre-optic cables will be sealed with 3M EC-1 type cap – Scotch 2228 type mastic tape is used to wrap and build-up the diameter of the fibre optic cable where the outer diameter of the FO cables are smaller than 11.6mm. Scotch 2228 is a conformable, self-fusing electrical rubber mastic tape with a strong, temperature stable adhesion for maximum continuous operation up to 90° Celsius.

The Changhua 1 and 2a offshore wind farms will comprise a total of 111 Siemens Gamesa 8 MW turbines. The offshore construction will be carried out during 2021 and 2022, with the project expected to be fully up and running in 2022.

Powering Data Centres

Thorne & Derrick have established an impressive project portfolio across UK, European and US built data centres; supporting the ever-changing industry and modern infrastructure changes with LV-HV Energisation & Electrical Equipment.

This month we supplied cable cleats and management products NTT’s Hemel Hempstead 2 (HH2) Global Data Centre. The HH2 facility provides 6MW of high quality data centre space across 6 data halls – each data hall has its own dedicated plant to a 2N configuration. With 30,000 square feet of net technical capacity, Hemel Hampstead 2 offers excellent connectivity options providing access to multiple carriers and cloud providers. 20kW is possible with high-power rack densities.

Technical Tips Playlist

Thorne & Derrick are the Specialist Distributor & Stockist for Nexans in the UK for their ranges of Cable Accessories up to 66kV. Nexans have created a 4 Part Video Playlist focusing on FAQ’s about their Euromold range of separable connectors.

Thorne & Derrick are the Specialist Distributor & Stockist for Nexans in the UK for their ranges of Cable Accessories up to 66kV. Nexans have created a 4 Part Video Playlist focusing on FAQ’s about their Euromold range of separable connectors.

Featured Jointers

132kV 3 Core Oil To Single Core XLPE Transition Cable Joint Without Sleeve

Read | Energi Cable Services Ltd | 132kV 3 Core Oil To 1 Core XLPE Transition Joint

Mita GRP | GRP Cable Containment Rail Solution

Containing Cables for Network Rail

Pictured: GRP Cable Containment Rail Solution | 300 metres of 110mm depth solid cable tray manufactured from GRP for a Network Rail project using PY1 type resin – several pallets are pictured at MITA prepared for despatch to the Reading Independent Feeder project which was originally part of CP6 enhancement scheme and constructed to minimise the impact of power and distribution failures on the operations of the GWML.

Thorne & Derrick can provide competitive prices and delivery for the complete range of MITA Cable Management & Containment Systems – contact us with your enquiries.

GRP Tray

Sector Spotlight | Offshore Wind

Thorne & Derrick International are Specialist Suppliers to the UK and international Offshore Wind Industry of products to provide safe and reliable Cable Termination, Jointing, Installation & Power Systems up to 66kV. Based in North-East England, we supply projects from the North Sea to the Nordics – our Exports Division support international offshore wind power projects from USA to China.

1 Block Island Offshore Wind Farm USA | Thorne & Derrick, as Approved Vendors to GE Renewable Energy supplied Earthing, Static Discharging & Electrical Safety Equipment to the substations plus a 33kV Cable Accessories package to power, joint and connect the medium voltage switchgear and transformers.

2 Operational Offshore Wind Farms (12 Locations) | Thorne & Derrick, as Approved Vendors to Orsted, supplied both standard and customised heat shrink joints manufactured by Nexans to enable planned maintenance and repair of the ABB, NKT, TFK & Prysmian High Voltage Cables – included land and subsea cable systems operating at 33kV.

3 Multiple Offshore Wind Farm Assets | Thorne & Derrick, as Approved Vendors to JDR Cable Systems, developed MV Jointers Tool Kits to provide offshore wind technicians with the specialist tools needed to prepare inter array cables up to 33kV prior to the installation of joints, terminations or connectors to the highest standard – included tools to enable the removal of the cable outersheath, insulation (XLPE) and semicon screens.

The Jointers Tool Kits are designed to provide their jointers with the specialist cable tools needed to prepare inter array cables up to 33kV prior to the installation of joints, terminations or connectors to the highest standard.

4 Bespoke & Standard Cable Clamps, Saddles & Cleats | Developed client customised cable support and cleat systems for high voltage cables in the nacelle/tower of WTG’s for a world leading manufacturer of wind turbines currently under NDA.

We are also approved vendors to SSE Renewables, Swire Energy Services (ALL NRG), Vestas Wind Systems A/S, Correll Group, Van Oord, Vattenfall, Boskalis and other leading renewable energy companies throughout the world.

5 Cable Pull-in Equipment | Working with Balfour Beatty plc on the Viking Link project Thorne & Derrick supplied a range of cable drum handling, socks, rollers and lubrication products to enable the safe pulling and trenching of high voltage power cables.

Image Courtesy | Max States Site Engineer at Balfour Beatty plc (Viking Link) – here the EHV 526kV cable is pictured being pulled from a 62 tonne cable drum (1240m circuit) into the cable trench via rollers in July 2021. Viking Link is a 1,400 MW HVDC submarine power cable under construction between the United Kingdom and Denmark.

Industry event

THORNE & DERRICK | EVENT SPONSORS

Thorne & Derrick are proud to be sponsoring the Earthing Conference UK this May in Birmingham.

The aim of this Earthing Conference UK is to demystify the subject of earthing and present the subject in a clear, straightforward manner. Earthing as a subject has been under-represented over the years and this event will attempt to remedy the gaps in technical knowledge and improve practices in the industry.

Read More About The Event | Earthing Conference 2022

www.events.idc-online.com

Phone: +44 (020) 8335 4014

Email: [email protected]

SPONSORSHIP OPPORTUNITIES

Representing your business at the Earthing UK Conference in 2022 will provide you the opportunity to reach key decision makers from a multitude of industries.

For more information on sponsorship and exhibition opportunities please contact: Emma Cameron at: [email protected]

The conference is currently seeking speakers who can talk about their experiences in the field, provide overviews of the applicable industry regulations/legislation and offer case studies and examples from industry. All presenters receive complimentary registration to attend the conference.

Jobs

Meet Mane

Mane Contract Services are committed to working with their client partners to help create a greener and cleaner future. For over 20 years, they have provided project staffing solutions to the complete project lifecycle across all Energy sources. Mane have an extensive project and client portfolio across both cable manufacturing & installation, working across UK, EMEA, APAC and USA.

Stephen Stuart and his team at Mane and they are looking to expand their network within the Wind Energy Industry;

– HV Engineering & Installation – 33kV, 132kV, 155kV, 220kV, 400kV
– Commissioning Engineering / Commissioning Management
– Installation Management & Package Management
– Grid Connection and Cable Installation
– Project Management / Construction Management
– Client Representation
– Site Management & Support
– Document Control & Management
– Project Planning / Scheduling– Project Controls Management
– Health & Safety Management

If you are recruiting for yourself or looking for a new career move within the Renewables sector then please get in touch +44 (0) 1923 470 724 or email: [email protected]

For more information – visit their jobs page; https://www.mane.co.uk/energy/

With a network of international offices around the world and a large dedicated team of specialist Account Managers and Head Hunters, Mane are well placed to support your career development or recruitment requirements around the globe.
