by Chris Dodds T&D - estimated reading time 5 minutes
Thorne & Derrick International, based in the UK, are a leading distributor of cable accessories and connection systems for 33kV cables – this includes heat shrink/cold shrink joints, terminations and EPDM type screened separable connectors manufactured by Nexans Euromold.
The following information enables the specification and selection of the correct 33kV cable plug type termination or connector to suit medium/high voltage power cables used with Siemens NXPLUS C Wind switchgear.
Specifically, we confirm the current approved 33kV cable connectors for use with Interface C 33kV Bushings on gas insulated switchgear.
The following information table enables the selection and outlines the possible cable connection types (T-Plugs, Coupling Insert & Screened Separable Connectors) and MV surge arresters compatible with Siemens NXPLUS C Wind switchgear 33kV/36kV.
Screened cable T-plugs, also known as separable connectors, are specified to terminate and connect 33kV power cables into Siemens NXPLUS C gas insulated switchgear – the external semi-conductive layer must be earthed normally via a cable connector.
Insulated cable T-plugs (without semi-conductive layer) are not permissible – this type of MV cable plug or connector is prone to partial discharge due to the proximity to earthed parts of the switchgear. Partial discharge destroys the MV cable connector causing an arc between phase and earth.
The connection of conventional 33kV cable sealing ends or terminations via elbow adapters is not permissible either as this type of medium voltage power system is also insulated but not screened (no external semi-conductive layer).
| Circuit-breaker Panels 630 A / 800 A 33kV/36kV | ||||||||
| Number Of Cables Per Panel & Phase | Connector Manufacturer | Rated voltage | Conductor Cross- Section sqmm | Cable Insulation | T-Plugs/Phase Bolted | Coupling Inserts/ Coupling Plugs / Bolted | Surge Arresters With Coupling Arresters/Phase | Inserts Coupling Unit |
| 1 | Nexans Euromold | 36kV | 50 to 240 | EPDM | 1x M400TB/G | – | 1x 400PB-5(10)SA-xxx | – |
| 36kV | 50 to 240 | EPDM | 1x M430TB/G | – | 1x 300SA-10-xx | – | ||
| 36kV | 50 to 630 | EPDM | 1x M484TB/G | – | 1x 800SA-10-xx | – | ||
| 36kV | 300 to 630 | EPDM | 1x M440TB/G | – | 1x 400PB-5(10)SA-xxx | – | ||
| Südkabel | 36kV | 70 to 300 | Silicone | 1x SET 36 | – | – | – | |
| 36kV | 70 to 500 | Silicone | 1x SEHT 33 | – | 1x MUT 33 | 1x KU 33 | ||
| nkt Cables | 36kV | 25 to 300 | Silicone | 1x CB 36-630 | – | 1x CSA36-10 | – | |
| 36kV | 400 to 630 | Silicone | 1x CB 36-630(1250) | – | 1x CSA36-10 | – | ||
| Tyco Electronics Raychem | 36kV | 25 to 300 | Silicone | 1x RSTI-66xx | – | 1x RSTI-CC-66SAxxx | – | |
| 36kV | 25 to 300 | Silicone | 1x RSTI-68xx | – | – | – | ||
| 36kV | 400 to 630 | Silicone | 1x RSTI-66Lxx | – | 1x RSTI-66SAxxx | 1x RSTIÂ66CP-M16 | ||
| 36kV | 400 to 800 | Silicone | 1x RSTI-69xx | – | – | – | ||
| 2 | Nexans Euromold | 36kV | 50 to 240 | EPDM | 2x M400TB/G | 1x M400CP | – | – |
| 36kV | 50 to 240 | EPDM | 1x M430TB/G | 1x M300PBM-630A | 1x 300SA-10-xx | – | ||
| 36kV | 50 to 360 | EPDM | 1x M484TB/G | 1x M804PB/G | – | – | ||
| 36kV | 300 to 630 | EPDM | 2x M440TB/G | 1x M400CP | – | – | ||
| Südkabel | 36kV | 70 to 500 | Silicone | 2x SEHT 33 | 1x KU 33 | – | – | |
| nkt cables | 36kV | 25 to 300 | Silicone | 1x CB 36-630 | 1x CC36-630 | 1x CSA36-10 | – | |
| 36kV | 25 to 300 | Silicone | 2x CB 36-630 | 1x CP 630C | – | – | ||
| 36kV | 400 to 630 | Silicone | 2x CB 36-630(1250) | 1x CC36-630(1250) | 1x CSA36-10 | – | ||
| 36kV | 400 to 630 | Silicone | 2x CB 36-630(1250) | 1x CP 630C | – | – | ||
| Tyco Electronics Raychem | 36kV | 25 to 300 | Silicone | 1x RSTI-66xx | 1x RSTI-CC-66xx | – | – | |
| 36kV | 25 to 300 | Silicone | 1x RSTI-68xx | 1x RSTI-CC-68xx | – | – | ||
| 36kV | 400 to 630 | Silicone | 2x RSTI-66Lxx | 1x RSTI-66CP-M16 | – | – | ||
| 36kV | 400 to 800 | Silicone | 1x RSTI-69xx | 1x RSTI-CC-69xx | – | – | ||
1) Observe the actual short-circuit and current carrying capacity of the cables and sealing ends
| Disconnector Panel 630 A / 800 A, ring-main panel 630 AÂ 33kV/36kV | ||||||||
| Number Of Cables Per Panel & Phase | Connector Manufacturer | Rated Voltage | Conductor Cross- Section sqmm | Cable Insulation | T-Plugs / Phase / Bolted | Coupling Inserts/ Coupling Plugs / Bolted | Surge Arresters With Coupling Arresters / Phase | Inserts Coupling Unit |
| 1 | Nexans Euromold | 36kV | 50 to 240 | EPDM | 1x M400TB/G | – | 1x 400PB 5(10) SA-xxx | – |
| 36kV | 50 to 240 | EPDM | 1x M430TB/G | – | 1x 300SA-10-xx | – | ||
| 36kV | 50 to 630 | EPDM | 1x M484TB/G | – | 1x 800SA-10-xx | – | ||
| 36kV | 300 to 630 | EPDM | 1x M440TB/G | – | 1x 400PB 5(10) SA-xxx | – | ||
| Südkabel | 36kV | 70 to 500 | Silicone | 1x SET 36 | – | – | – | |
| 36kV | 70 to 500 | Silicone | 1x SEHT 33 | – | 1x MUT33 | 1x KU33 | ||
| nkt Cables | 36kV | 25 to 300 | Silicone | 1x CB36-630 | – | 1x CSA36-10 | – | |
| 36kV | 400 to 630 | Silicone | 1x CB36-630(1250) | – | 1x CSA36-10 | – | ||
| Tyco Electronics Raychem | 36kV | 25 to 300 | Silicone | 1x RSTI-66xx | – | 1x RSTI-CC-66SAxxx | – | |
| 36kV | 25 to 300 | Silicone | 1x RSTI-68xx | – | – | – | ||
| 36kV | 400 to 630 | Silicone | 1x RSTI-66Lxx | – | 1x RSTI-CC-66SAxxx | 1x RSTI-66CPÂM16 | ||
| 36kV | 400 to 800 | Silicone | 1x RSTI-69xx | – | – | – | ||
| 2 | Nexans Euromold | 36kV | 50 to 240 | EPDM | 2x M400TB/G | 1x M400CP | – | – |
| 36kV | 50 to 240 | EPDM | 1x M430TB/G | 1x M300PB/G | – | – | ||
| 36kV | 50 to 630 | EPDM | 1x M484TBG | 1x M804PB/G | 1x 800SA-10-xx | – | ||
| 36kV | 300 to 630 | EPDM | 2x M440TB/G | 1x M400CP | – | – | ||
| Südkabel | 36kV | 70 to 500 | Silicone | 2x SEHT 33 | 1x KU33 | – | – | |
| nkt Cables | 36kV | 25 to 300 | Silicone | 1x CB36-630 | 1x CC36-630 | 1x CSA36-10 | – | |
| 36kV | 25 to 300 | Silicone | 2x CB36-630 | 1x CP-630C | 1x CSA36-10 | – | ||
| 36kV | 400 to 630 | Silicone | 1x CB36-630(1250) | 1x CC36-630(1250) | 1x CSA36-10 | – | ||
| 36kV | 400 to 630 | Silicone | 2x CB36-630(1250) | 1x CP-630C | – | – | ||
| Tyco Electronics Raychem | 36kV | 25 to 300 | Silicone | 1x RSTI-66xx | 1x RSTI-CC-66xx | 1x RSTI-CC-66SAxxx | – | |
| 36kV | 25 to 300 | Silicone | 1x RSTI-68xx | 1x RSTI-CC-68xx | – | – | ||
| 36kV | 400 to 630 | Silicone | 2x RSTI-66Lxx | 1x RSTI-66CP-M16 | 1x RSTI-CC-66SAxxx | 1x RSTI-66CPÂM16 | ||
| 36kV | 400 to 800 | Silicone | 1x RSTI-69xx | 1x RSTI-CC-69xx | – | – | ||
| 3 | Nexans Euromold | 36kV | 50 to 240 | EPDM | 1x M430TB/G | 1x M300PBM- 630A | – | – |
| nkt Cables | 36kV | 25 to 300 | Silicone | 1x CB36-630 | 2x CC36-630 | – | – | |
| 36kV | 2x CP-630C | – | – | |||||
| 36kV | 400 to 630 | Silicone | 1x CB 36-630(1250) | 2x CC36-630(1250) | – | – | ||
| 36kV | 400 to 630 | Silicone | 2x CB 36-630(1250) | 1x CP-630C | – | – | ||
| Tyco Electronics Raychem | 36kV | 25 to 300 | Silicone | 1x RSTI-66xx | 2x RSTI-CC-66xx | – | – | |
| 36kV | 25 to 300 | Silicone | 1x RSTI-68xx | 2x RSTI-CC-68xx | – | – | ||
| 36kV | 400 to 630 | Silicone | 3x RSTI-66Lxx | 2x RSTI-66CP-M16 | – | – | ||
| 36kV | 400 to 800 | Silicone | 1x RSTI-69xx | 2x RSTI-CC-69xx | – | – | ||
1) Observe the actual short-circuit and current carrying capacity of the cables and sealing endsÂ
The following table outlines the screened separable connector, also referred to as cable sealing ends, suitable for 33kV/36kV cables according to IEC 60502-2 and VDE 0276-620.
The cable T-plug connection types are suitable for medium voltage bushings with outside cone as Interface C Type Bushings according to EN50181 for 33kV cables with conductor cross-section up to 800sqmm copper/aluminium.
| Cable Type 33kV/36kV | Connector Manufacturer | 33kV Cable Connector Type | Cross-Section sqmm | Comment |
| 1-core cable, PE and XLPE- insulatedN2YSY (Cu) and N2XSY (Cu) orNA2YSY (Al) and NA2XSY (Al) | Nexans Euromold | M400TB/G | 50 to 240 | EPDM with semi-conductive layer |
| M430TB/G | 50 to 240 | EPDM with semi-conductive layer | ||
| M484TB/G | 70 to 630 | EPDM with semi-conductive layer | ||
| M440 TB/G | 300 to 630 | EPDM with semi-conductive layer | ||
| nkt cables | CB 36-630 | 25 to 300 | Silicone with semi-conductive layer (optionally with metal housing) | |
| CB 36-630(1250) | 400 to 630 | Silicone with semi-conductive layer (optionally with metal housing) | ||
| Südkabel | SEHDT 33 | 70 to 500 | Silicone with semi-conductive layer (optionally with metal housing) | |
| Tyco Electronics Raychem | RSTI-66xx | 25 to 240 | Silicone with semi-conductive layer, with capacitive measuring point | |
| RSTI-68xx | 25 to 240 | Silicone with semi-conductive layer, with capacitive measuring point | ||
| RSTI-66Lxx | 400 to 630 | Silicone with semi-conductive layer, with capacitive measuring point | ||
| RSTI-69xx | 400 to 800 | Silicone with semi-conductive layer, with capacitive measuring point |
N2XSY XLPE PVC – 18/30 (36)kV Cable Connectors
Surge arresters for pluggable onto cable T-plugs and are recommened for MV-HV cable and power systems:
| Surge Arrester 33kV/36kV | 1 Cable Per Phase | 2 Cables Per Phase | ||||
| Circuit-breaker Panel | Disconnector Panel | Ring-main Panel | Circuit-breaker Panel | Disconnector Panel | Ring-main Panel | |
| Nexans Euromold 400PB-10-SA-45L | X | X | X | – | – | – |
| Nexans Euromold 300SA-10-xx | X | X | X | X | X | X |
| Südkabel MUT 33 + KU 33 | – * | X | X | – | – | – |
| nkt Cables CSA 36-10 | X | X | X | X** | X | X |
| Tyco Electronics Raychem RSTI-CC-66SAxxx | –* | X | X | –* | X | X |
| Tyco Electronics Raychem RSTI-66SAxxx | –* | X | X | –* | X | X |
* protrudes into the floor area; possible depending on the local conditions, e.g. with sufficient hole depth
** depending on the cable plug type – contact T&D to discuss possible combinations of cable connection types and surge arresters in NXPLUS C Wind up to 36kV.
âž¡ View complete range of Surge Arresters 11kV 33kV MV HVÂ
Screened separable connectors and surge arresters must be provided by the same manufacturer and used only with one cable connected per 33kV phase. Some types of surge arresters exceed the permissible dimensions as outlined in the table above.
Ellis Patents | Nexans | ABB Furse | Prysmian | Pfisterer – Distributors
Credit Nexans – contact us for HV Cable Joints, Terminations & ConnectorsÂ
Credit ABB – Joint, Terminate & Connect Medium & High Voltage Cables
T&D are UK distributors and worldwide exporters of Cable Installation, Cable Jointing, Duct Seals, Substation & High Voltage Electrical Safety Equipment – we service UK and global businesses involved in cable installations, jointing, substation, overhead line and electrical construction at LV, 11kV, 33kV and EHV.
Since 1985, T&D have established a solid reputation based on Service, Integrity and Trust – contact us with your enquiry.
by Chris Dodds T&D - estimated reading time 5 minutes
Here, high voltage substation cables are shown connected and terminated into switchgear using 33kV cable terminations.
The copper earthing tapes are used to bond all of the cable glands together which are providing mechanical retention to the 33kV high voltage power cables.
The earth tapes are clamped and attached to the substation earthing system as they are insulated from the 33kV cable box and high voltage oil-filled switchgear. The whole bank of HV switchgear is insulated from the ground and has its own earth which runs through a Current Transformer (CT) for protection reasons – the separate ‘frame earth’ is painted green in the photograph below. The stand for the cable cleats was also bonded to the substation earth. As there is a steel sandwich plate fitted to the front of the wooden cable cleats the threaded bar used is stainless steel to avoid circulating currents.
Client specified expanding foam has been used to seal the substation cable ducts within the high voltage substation – outside the substation the 33kV cable ducts were effectively sealed using a specified system to provide certain protection against water ingress and gas migration using recognised systems such as the CSD RISE duct seal or Filoform Filoseal re-enterable cable seals.
The insulating oil is usually heated before the high voltage cable box is dismantled by venting it above and heating with halogen heaters.
The 33kV cables were stripped using the correct cable jointing tools – the PVC cable sheath was thoroughly stripped from the high voltage power cable using the Boddingtons “plough” type sheath stripper. The cable jointer then removed the XLPE insulation cleanly and without damaging the cable using Alroc LH2 tool suitable for cable stripping HV cables up to 60mm.
Finally, Alroc CWB 18-60 tool was used to remove the bonded semicon from the cable – the “blue tool” manufactured by Alroc is preferred by jointers for working on medium/high voltage power cables where a clean square cut of the semicon without jagged finish is vital to the long term reliability of power cable performance.
Poor cable jointing skills with respect to MV-HV cable preparation can create future cable failure potential – it is critical a skilled jointer uses the correct cable tools to prepare MV-HV cables before installing joints, terminations or connectors up to 33kV.
